TECHNICAL DATA
technical data
TECHNICAL DATA
Appliance dimensions
Width 575 mm
Depth 505 mm
Height 56 mm
Worktop cut - out dimensions
Width 560 mm
Depth 490 mm
Corner radius 3 mm
Connection voltage 220 - 240 V ~ 50 / 60 Hz
Maximum connected load power 7.2 kW
Weight
Net 11.3 kg
Gross 14.2 kg
COOKING ZONES
Position Diameter Power
Rear left 160 mm 1400 W / Boost 2000 W
Front left 210 mm 2200 W / Boost 3200 W
Front Bridge - 1800W / Boost 2600W
Rear Bridge - 1800W / Boost 2600W
Complete Bridge - 3600W / Boost 4600W
