technical data
TECHNICAL DATA
Appliance
dimensions
Width 590 mm
Depth 505 mm
Height 52 mm
Worktop cut - out
dimensions
Width 560 mm
Depth 490 mm
Corner radius 3 mm
Connection voltage 220 - 240 V ~ 50/60 Hz
Maximum connected load power 7.1 kW
COOKING RINGS
Position Diameter Power
Front left 120 / 175 / 215 mm 800 / 1600 / 2300 W
Rear left 148 mm 1200 W
Rear right 170 / 265 mm 1500 / 2400 W
Front right 148 mm 1200 W
