DCS Compact II General Description Chapter 2. Hardware Descriptions
2-4
6 MWSLI card (KP70D–B6S2/) Available from July, 1998
The 6 MWSLI card provides six SLI ports for industry–standard single line
telephones and the ability to provide a loop disconnect signal and a message
waiting signal. Please note that this card does not provide Long Line protection.
KDb–DLI, KDb–SLI card
The KDb–DLI board or KDb–SLI board, if installed in a digital keyset connecting
to the Basic KSU, provides a second DLI or SLI port.
2.4 Specifications
The following tables provide technical data for the DCS Compact II hybrid/key
telephone system.
Electrical Specifications
AC INPUT
220 VAC ± 20%, 48–63 Hz
or Free Input Voltage for some countries.
POWER CONSUMPTION (MAX)
100 WATTS MAX
DC OUTPUT
FUSE RATING 2.0 AMP
+5 VOLTS 2.5 AMPS MAX
–5 VOLTS 0.5 AMPS MAX
(on the Motherboard)
–55 VOLTS 1.2 AMPS MAX
–54 VOLTS 0.4 AMPS MAX
