DCS Compact II General Description
i
TABLE OF CONTENTS
CHAPTER 1 System Overview ...........................................1–1~1–6
1.1 Introduction.................................................................................................1–1
1.2 Size and Configuration...............................................................................1–2
1.3 Technology...................................................................................................1–5
1.4 Programming................................................................................................1–6
CHAPTER 2 Hardware Descriptions................................. 2–1~2–6
2.1 Key Service Unit ..........................................................................................2–1
2.2 Expansion Cabinet.......................................................................................2–2
2.3 Interface Cards............................................................................................2–2
2.4 Specifications...............................................................................................2–4
CHAPTER 3 Station Equipment.......................................... 3–1~3–5
3.1 LCD 24B Model Keyset (Figure 3–1).........................................................3–1
3.2 STD 24B Model Keyset (Figure 3–2) .........................................................3–2
3.3 LCD 12B Model Keyset (Figure 3–3).........................................................3–3
3.4 STD 12B Model Keyset (Figure 3–4)........................................................3–3
3.5 Enhanced 6B Model Keyset (Figure 3–5)..................................................3–4
3.6 48 Button Add–On Module (AOM) (Figure 3–6, 3–7)............................3–4
3.7 Door Phone Interface Module (DPIM) And Door Phone
(Figure 3–8, 3–9).........................................................................................3–5
CHAPTER 4 Features ........................................................ 4–1~4–34
4.1 System Features ...........................................................................................4–1
4.2 System Feature Descriptions.......................................................................4–2
4.3 Station Features..........................................................................................4–21
4.4 Station Feature Descriptions.....................................................................4–22
4.5 Display Features........................................................................................4–29
4.6 Display Feature Descriptions ...................................................................4–29
