 The clothes are not dried.
TheproblemisinthePCB
assembly.Pleasereplaceit.
Installtheventsothatitisnotblockedtotheoutside.
(Checktheexhausthole)
Cleanthelter.
(Checkifthereareanyalienparticlesin
thelter)
Connecttheterminalblockproperly.
(ChecktheconnectionofLive2,Neutral,
Live 1)
Neutral
Earth
L2
L1
Connectthetouchsensor.
(CheckthePCBandtouchsensor)
Istheventproperly
installed?
Yes
No
ChecktheSafety,Hi-Limitthermostat.
(Checkthecauseofsafetybeingoff)
Didyoucleanthe
lterbeforedrying?
Yes
No
Istheterminalblock
connectionnormal?
Yes
No
Isthetouchsensor
normal?
Yes
No
IstheTamp.Sensor
normal?
Yes
No
Isthesafety,Hi-limit
thermostatnormal?
Yes
No
Istheheaternormal?
Yes
No
Replacethethermistor
(Checktheconnectionbetweenthe
PCBandtermistorandcheckforany
disconnection)
Replacetheheater
(Removethepowerandcheckwhetherthe
heatercoilhasaresistanceofabout10Ω)
