Exploded views and Parts list _ 39
MODEL CODE: DV220AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un
SA/
SNA
0 DV220AEW_XAA ASSY-CLOTHES DRYER
1 DC97-15162A ASSY FRAME FRONTIER4,DV218AEW,-,-,-,- 1 PC SA
2 DC63-00534B COVER-BACK WINGS-DRYER,GI,T0.6,-,-,-,-,NTR,- 1 PC SA
3 DC97-08855A ASSY-COVERPOWER MDE9700AYW,- 1 PC SA
3-1 DC63-00540A COVER-POWER WINGS-DRYER,GI,T0.6,-,-,-,-,NTR,- 1 PC SNA
3-2 DC72-00056A SPONGE-CUSHION 27-DRYER,UN2,-
,T3.0,W50,L100,BLACK,NONE BURN
1 PC SNA
4 DC61-01428A HOLDER-POWER MDE9700AYW,PP,-,-,-,WHT,POWER CORD 1 PC SA
5 DC97-08634K ASSYCOVERTOP DV316LEW,-,T0.8,-,-,WHT 1 PC SA
6 DC93-00151A ASSY M. WIRE HARNESS BIG BANG
DRYER,DV220AEW,120/240,NO
STEAM,DUCT STEEL,ELECTRIC
1 PC SA
7 DC97-10875L ASSY HOLDER PCB BIGBANG-DRYER,DV220AEW,N 1 PC SNA
7-1 DC61-01229A HOLDER-PCB WINGS-DRYER,GI,T0.6,NTR,MAIN PCB
HOLD
1 PC SA
7-2 DC92-00123C ASSY PCB MAIN BIG-BANG DRYER
MAIN,DV220AEW,120V/60HZ,-,1888/
LED,Y,LINEAR
1 PC SA
8 DC97-15944A ASSY FRAME PLATE(U) BIGBANG-PJT,DV220AEW/XAA,T0.8 1 PC SNA
8-1 DC61-02570A FRAME-PLATE(U) DV220AEW,GI,T0.8,W673.0 1 PC SA
9 DC97-15962A ASSY PANEL CONTROL BIGBANG-DRYER,DV220,WHITE,ENG 1 PC SNA
10 ASSY-FRAME FRONT &
DOOR
Refer to 5.2 FRAME FRONT & DOOR 1
11 DC97-15961A ASSY DRUM BIGBANG-DRYER,DV220AEW 1 PC SNA
12 DC93-00147A ASSY MOTOR DUCT BIGBANG-DRYER,DV220,120V,60Hz 1 PC SNA
13 DC97-07519A ASSYDUCTEXHAUST WINGS-DRYER,MDE9700AYW,-,-,- 1 PC SA
14 DC97-14486A ASSY DUCT HEATER 27-DRYER,-,-,-,ELECTRIC,- 1 PC SA
15 DC61-02020B BRACKET-COVERTOP -,GI,T1.6,-,-,-,DRYER 2 PC SA
16 DC97-12150A ASSY LEG MARS-PJT,DRYER,-,-,-,- 4 PC SA
16-1 DC61-01226A BRACKET-LEG WINGS-DRYER,SGCC(GI),T1.6,-,-,-,- 1 PC SA
16-2 DC61-01693A LEG MARS-PJT,FRPP,-,-,-,- 1 PC SA
