Exploded views and Parts list _ 43
MODEL CODE: DV220AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un
SA/
SNA
0 ASSY-FRAME FRONT &
DOOR
1
1 DC97-15907B ASSY DOOR BIG-BANG
DRYER,DV220AEW,SILVER+GRAY
1 PC SA
1-1 6001-001668 SCREW-MACHINE TH,+,M5,L16,PASS,STS430,FP,NYLOCK 1 PC SA
1-2 6002-000234 SCREW-TAPPING TH,+,-,2S,M4,L16,ZPC(WHT),SWRCH18A,- 12 PC SNA
1-3 6002-000445 SCREW-TAPPING TH,+,2,M4,L18,PASS,STS304 2 PC SA
1-4 6002-001306 SCREW-TAPPING TH,+,-,1,M4,L14,ZPC(WHT),SWRCH18A,- 8 PC SNA
1-5 DC61-00891A GUIDE-HINGE HAUZEN(DOM),POM,-,-,-,WHT,HINGE 4 PC SA
1-6 DC61-01532C HINGE-DOOR WF210ANW,ALDC,T3.8,W173,L40.6,BLA
CK
1 PC SA
1-7 DC61-01576A SUPPORT-HINGE FRONTIER-PJT,SBHG1-A(SGCC),T1.4,-,-,-
,HOLDER-GLASS(GI)
1 PC SA
1-8 DC61-02551A HOLDER-GLASS DV220,PP,W479.4,DARKHOLDER
GRY(G61432),BIG-BANG DRYER
1 PC SA
1-9 DC62-00291A SEAL-DOOR DV220,TPE,DARKHOLDER
GRY,T18.1,BIG-BANG
1 PC SA
1-10 DC63-01126B COVER-DOOR DV220AEW,ABS,T2.5,IMPERIAL-
SILVER,BIG-BANGDRYER
1 PC SNA
1-11 DC63-01127A COVER-DOOR(I) DV220,ABS,W456,L503,GRAY(G61432),B
IG-BANG
1 PC SA
1-12 DC64-02092B HANDLE-DOOR DV220,ABS,W187,L74.4,DARKHOLDER
GRAY,BIG-BANG
1 PC SA
1-13 DC64-02093A DOOR-GLASS DV220,Tempered
GLASS,T3.2,W357xL357,TRP
1 PC SA
1-14 DC64-02094A DOOR-SAFETY DV220,PET,T2.5,H27.3,W400.4,TRP,BIG-
BANG DRYER
1 PC SA
1-15 DC66-00395A LEVER-DOOR WINGS-DRYER,POM,-,-,-,-,NTR,- 1 PC SA
2 6001-001773 SCREW-MACHINE TH,+,-,M5,L12,PASS,STS430,-,SEAL-
LOCK
2 PC SA
3 6006-001174 SCREW-TAPPING TH,+,WE,2S,M4,L12,ZPC(WHT),SWRCH
18A
4 PC SNA
4 DC97-15941A ASSY FRAME FRONT BIGBANG-
DRYER,DV220AEW,T0.7,WHITE
1 PC SA
4-1 6001-001773 SCREW-MACHINE TH,+,-,M5,L12,PASS,STS430,-,SEAL-
LOCK
2 PC SA
4-2 6002-000231 SCREW-TAPPING TH,+,NO,2S,M4,L12,ZPC(WHT),SWRCH
18A
2 PC SNA
4-3 DC61-01222A BRACKET-HINGE 27-DRYER,HGI,T2.0,-,-,-,- 2 PC SA
4-4 DC61-02571A FRAME-FRONT DV220AEW,EGI,WHT,T0.7,W684.0,H816.0 1 PC SNA
4-5 DC63-10001C SPONGE-EPDM -,EPDM,-,T3.0,W15,L350,BLK,OJC3000 4 PC SA
4-6 DC64-00828A DOOR-S/W GD-PJT,PA,T13.6,H38.5,W44.3,-
,WHT,120V/15ASPE110F
1 PC SA
4-7 DC97-07510B ASSYHOLDERLEVER -,MDE7800AYW,DRYER/DOOR LOCK,-,-,- 1 PC SA
