Exploded views and Parts list _ 47
MODEL CODE: DV220AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un
SA/
SNA
0 DC97-15962A ASSY PANEL CONTROL BIGBANG-DRYER,DV220,WHITE,ENG 1 PC SNA
1 DC92-00303B ASSY PCB SUB BIGBANGDRYERSUB,DV220AEW,120V/
60HZ,1888/LED,N
1 PC SA
2 DC97-14447D ASSY KNOB ENCODER BIGBANG,WF210ANW,ABS(DECO-
ENCODER)
1 PC SA
2-1 DC64-01642B KNOB-ENCODER SEW-HVR149AD,ABS,T2.0,BLACK,Spray 1 PC SNA
2-2 DC64-01643A DECORATION-ENCODER(I) SEW-HVR149AD,ABS,T2.5,N,NTR,CR-
COATING
1 PC SNA
2-3 DC64-01813A DECORATION-ENCODER SEW-HMR147ATR,ABS,-,-,OD57.4,HB,-,AL
VAPORDEPOSITION
1 PC SNA
3 DC97-15940A ASSY S.PANEL CONTROL BIGBANG-PJT,DV220AEW,WHT 1 PC SA
3-1 DC64-02114A PANEL-CONTROL DV220AEW,ABS,T3.0,W682.0,WHT 1 PC SNA
3-2 DC97-15939A ASSY BUTTON BIGBANG-PJT,DV220AEW,BLACK 1 PC SA
3-2-1 DC63-01137A COVER-BUTTON DV220AEW,ABS,W372.6,BLACK 1 PC SNA
3-2-2 DC64-02115A WINDOW-PANEL DV220AEW,ABS,T2.0,W359.5,TRP-BLK 1 PC SNA
3-2-3 DC64-02116A BUTTON-PUSH(O) DV220AEW,ABS,W16.0,BLACK,Option-1 1 PC SNA
3-2-4 DC64-02117A BUTTON-PUSH(O) DV220AEW,ABS,W16.0,BLACK,Option-2 1 PC SNA
3-2-5 DC64-02118A BUTTON-PUSH(O) DV220AEW,ABS,W16.0,BLACK,Option-3 1 PC SNA
3-2-6 DC64-02119A BUTTON-PUSH(F) DV220AEW,ABS,W34.9,BLACK,Function-1 1 PC SNA
3-2-7 DC64-02120A BUTTON-PUSH(F) DV220AEW,ABS,W34.9,BLACK,Function-2 1 PC SNA
3-2-8 DC64-02121A BUTTON-PUSH(F) DV220AEW,ABS,W34.9,BLACK,Function-3 1 PC SNA
3-2-9 DC64-02122A BUTTON-PUSH(P) DV220AEW,ABS,BLACK 1 PC SNA
3-2-10 DC64-02123A BUTTON-RUBBER DV220AEW,SILICON,T1.5/W172.0,TRP 1 PC SNA
3-2-11 DC64-02124A DECORATION-BUTTON DV220AEW,ABS,W173.5,BLACK 1 PC SNA
