Exploded views and Parts list _ 51
MODEL CODE: DV220AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un
SA/
SNA
0 DC97-15961A ASSY DRUM BIGBANG-DRYER,DV220AEW 1 PC SNA
1 DC97-16013A ASSY CASE FILTER BIGBANG-PJT,DV220AEW 1 PC SA
1-1 DC61-02610A CASE-FILTER(U) BIG-BANGDRYER,PP,GRAY,DV220AEW 1 PC SA
1-2 DC61-02613A CASE-FILTER BIG-BANGDRYER,PP,GRAY,DV220AEW 1 PC SA
2 DC97-07526B ASSY DUCT OUTLET DV337AEW,DRYER/BRACKET-
APPLIED,-,-,-
1 PC SA
2-1 6041-001035 RIVET-RH K1661-0512,AL(A5052),OD3.9,L11,NTR 2 PC SNA
2-2 DC61-01667A BRACKET-FILTER(U) MDE9700AYW,GI,T1.0,-,-,-,UPPER 1 PC SNA
2-3 DC63-10001K SPONGE-EPDM SWF-P12,EPDM,-,T3,W15,L530,BLK,- 1 PC SNA
2-4 DC67-00127A DUCT-OUTLET(F) WINGS-DRYER,GI,T0.35,-,-,NTR,FRONT 1 PC SNA
2-5 DC67-00128B DUCT-OUTLET(B) DV337AEW,GI,T0.6,-,-,NTR,2-HOLES 1 PC SNA
2-6 DC72-00032A SPONGE-EPDM MDE9700AYW,EPDM,-
,T5,W20,L400,BLK,DUCT-OUTLET(F)
1 PC SNA
2-7 DC72-00032C SPONGE-EPDM MDE9700AYW,EPDM,-
,T5,W20,L380,BLK,DUCT-OUTLET(B)
1 PC SNA
3 DC97-15958A ASSY DRUM FRONT BIG-BANGDRYER,DV220AEW,T1.0 1 PC SNA
3-1 DC47-00021A SOCKET-LAMP -,MDE7800,E12,125V,0.6A,-
,125V75W,-,-,-,-,-
1 PC SA
3-2 DC60-50145A NUT-HEX MSWR,M10 2 PC SNA
3-3 DC60-60060A WASHER -,T2,-,ID12,OD24,-,YEL,- 4 PC SA
3-4 DC61-01220A GUIDE-LAMP 27-DRYER,FH44N,-,-,-,BLK,INTERIOR
LAMP
1 PC SA
3-5 DC63-00531A COVER-LAMP WINGS-DRYER,PC(LEXAN#141R),-,-,-,-,-
,-,TRP
1 PC SA
3-6 DC97-07523B ASSY ROLLER -,27-DRYER,DRYER/EPDM,-,-,- 2 PC SA
3-6-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-
,NTR,ROLLER
2 PC SA
3-7 DC97-15957A ASSY-S.DRUM FRONT BIG-BANGDRYER,DV220AEW,T1.0 1 PC SA
3-8 DC63-01144A COVER-FILTER(U) BIG-BANGDRYER,PP,GRAY,DV220AEW 1 PC SA
3-9 DC61-02740A SPRING ETC-FILTER BIGBANG-
DRYER,HSWR,PI0.6,ID4.3,OD5.5,6
TURNS
1 PC SA
3-10 DC63-01149A COVER-FILTER(B) BIG-BANGDRYER,PP,GRAY,DV220AEW 1 PC SA
3-11 DC63-01150A COVER-FILTER(F) BIG-BANGDRYER,PP,GRAY,DV220AEW 1 PC SA
3-12 4713-001199 LAMP-INCANDESCENT 120V,83mA,10W,NTR,-,-,22x54mm 1 PC SA
3-13 DC96-00766A ASSY WIRE HARNESS GR-PJT,-,-,SUB/TOUCHSENSOR,-,- 1 PC SA
3-14 DC61-02627A PLATE-SENSOR DV220AEW,STAINLESS-
STS430,T0.8,TOUCH-SENSOR
2 PC SA
4 DC97-07520F ASSY DRUM WRAPPER FRONTIER,POWDER COATING,-,-,-,- 1 PC SA
4-1 DC66-00405B DRUM-WRAPPER 27-DRYER,SECC(EGI 0.6T),625.3,OD667.
3,L560,WHITE,POWDER COAT
1 PC SNA
4-2 DC66-00436A DRUM-LIFTER DV736E4/XAA,PP,GRY,FRONTIER-
DRYER
3 PC SA
4-3 DC97-07618A ASSY GASKET PAD MDE9700AYW,DRYER/DRUM-
WRAPPER,-,-,-,-
2 PC SNA
5 DC97-08698B ASSY DRUM BACK DV206AEW/XAA,EGI(POWDERCOAT)
0.6T,-,-,-,-
1 PC SNA
5-1 DC60-50145A NUT-HEX MSWR,M10 2 PC SNA
