54 _ Exploded views and Parts list
MODEL CODE: DV220AGW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un
SA/
SNA
5-1 DC60-50145A NUT-HEX MSWR,M10 2 PC SNA
5-2 DC60-60060A WASHER -,T2,-,ID12,OD24,-,YEL,- 4 PC SA
5-3 DC61-01237A BRACKET-DRUM BACK WINGS-DRYER,SBHG1-A,T0.8,TOP/
SGCC(GI)
1 PC SNA
5-4 DC61-01238A BRACKET-DRUM BACK 27-DRYER,SBHG1-A,T0.8,-,-,-,SIDE/
SGCC(GI)
2 PC SNA
5-5 DC66-00411B DRUM-BACK 27-DRYER,EGI(T0.6),-,-,-,WHT,POWDER
COAT
1 PC SA
5-6 DC97-07521C ASSY DUCT AIR MDG9700AWW,-,-,-,GAS DRYER/WING
TYPE,-
1 PC SA
5-7 DC97-07523B ASSY ROLLER -,27-DRYER,DRYER/EPDM,-,-,- 2 PC SA
5-7-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-
,NTR,ROLLER
2 PC SA
5-8 DC61-02593A BRACKET-ROLLER DV220AEW,GI,T1.2,W117.9,NTR 1 PC SNA
6 DC61-02773A DIE-RACK DRY SQUALL-DRYER,PP,GRY 1 PC SA
