Exploded views and Parts list _ 57
MODEL CODE: DV220AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un
SA/
SNA
0 DC93-00147A ASSY MOTOR DUCT BIGBANG-DRYER,DV220,120V,60Hz 1 PC SNA
1 DC93-00101A ASSY MOTOR ACE,DRYER,120V,60Hz 1 PC SA
1-1 6021-001201 NUT-INCH LEFT TURN,3/8"-
24,ZPC(YEL),MSWR10,INCH
1 PC SA
1-2 DC67-00180A FAN WINGS-DRYER,FRPP(15%),-,-,-,MOTOR 1 PC SA
1-3 DC93-00098A ASSYCOVERDUCT ACE-DRYER,DV419,W103.7 1 PC SA
1-3-1 DC63-01026A COVER-DUCTFAN 27-DRYER,GI,T0.6,-,-,-,-,-,- 1 PC SNA
1-3-2 DC61-02364A GUIDE-FAN 27-DRYER,PP(TB53),T2.0,-,L100,-,- 1 PC SNA
1-3-3 DC61-02348A GUIDE-DUCT FAN 27-DRYER,GI,T0.6,-,-,-,- 1 PC SNA
1-4 DC31-00055D MOTOR INDUCTION-DRYER dryermotor,DFS270ZSEL,4,110V-
120V,60Hz,5,1/3HP,B,1625,27"DRYER
1 PC SA
1-5 DC96-00790C ASSY BRACKET MOTOR MDE9700AYW,DRYER,-,-,-,- 1 PC SNA
1-5-1 3405-001077 SWITCH-MICRO 125V,15A,180gf,2 1 PC SA
1-5-2 6002-000488 SCREW-TAPPING PH,+,-,2S,M3,L16,ZPC(WHT),SWRCH18A,- 1 PC SA
1-5-3 6009-001342 SCREW-SPECIAL TH,+,-,M5,L11,ZPC(WHT),SWRCH18A,MA
CHINE,2BODY
1 PC SA
1-5-4 DC61-01213A BRACKET-MOTOR WINGS-DRYER,HGI,T2.0,-,-,-,- 1 PC SA
1-5-5 DC61-01215B SPRING ETC-TENSION MDE9700AYW,HSWR,D1.8,-,D15,-
,22TURNS,-,ZPC2,-,-
1 PC SA
1-5-6 DC96-00882C ASSY BRACKET IDLER MDE9700AYW,DRYER,-,-,-,- 1 PC SA
1-5-6-1 DC61-01228A HOLDER-SHAFT WINGS-DRYER,NYLON#6,-,-,-
,NTR,ROLLER
1 PC SA
1-5-6-2 DC61-01230B BRACKET-IDLER MDE9700AYW,HGI,T2.0,-,-,-,- 1 PC SA
1-5-6-3 DC66-00401A SHAFT-IDLER WINGS-DRYER,STS-410,-,-,-,-,FORMER 1 PC SNA
1-5-6-4 DC97-07509B ASSY ROLLER -,MDE9700AYW,DRYER/MOTOR/
IDLER,-,-,-
1 PC SA
1-5-6-4-1 DC66-00402A ROLLER-IDLER WINGS-DRYER,POM,-,-,-,-,MOTOR 1 PC SA
1-5-7 DC63-00919A COVER-SWITCH DV448,ABS+PC,T1.5,W13.7,L52,UL94-
V0,NATURAL
1 PC SA
1-6 DC61-01214A SPRING-PLATE WINGS-DRYER,SK-5,-,-,-,-,-,-,-,-,MOTOR 2 PC SA
1-7 DC32-00007A THERMISTOR N3S1-K41-S1,10K,10KOHM 25,-40~105,-
,5,-,5,N3S1-K41-S1
1 PC SA
1-8 DC47-00016A THERMOSTAT PW-3V,AC125/250V,25A,85±5,-
35,25A,16,100Mohm,SAFETY
1 PC SA
2 6602-001655 BELT-TIMING GEAR -,RUBBER,T3*W8,-,L2337,BLK 1 PC SA
3 DC97-07895A ASSY DUCT CONNECTOR MDE7800AYW,DRYER,-,-,ELECTRIC,- 1 PC SA
3-1 DC67-00130A DUCT-CONNECTOR 27-DRYER,PP,NTR,PREMIUM 1 PC SNA
3-2 DC72-00032E SPONGE-EPDM MDE9700AYW,EPDM,-
,T3,W15,L740,BLK,COVER-FAN
1 PC SNA
