10 _ Disassembly and Reassembly
Part Figure Description
Drum Removal
1. DisconnectthePowerSupplytotheunit.
2. RemovethePanelControl,theMainPCB,the
CoverTop,theFrameFrontandtheDrumFront.
3. RemoveBelt.
4. RemovetheDrum.
 Whenreassemblethebelt,makeitlocated
middleoftheDrum.
Sensor
(Thermistor,
Thermostat)
Removal
1. Disconnectthepowersupplytotheunit.
2. RemovethePanelControl,theMainPCB,the
CoverTop,theFrameFront,theDrumFrontand
theDrum.
3. Remove2HousingSensor.
4. RemovetheSensor.
 Donotapplyexcessiveforcetotheterminal.
