Samsung Electronics 4-3
No Parts Procedure Remark
3 Bracket Body
Element, B
1) Remove the 4 bolts and separate Bracket
Body Element, B. (Use +Screw Driver.)
4 Ass’y Element 1) Pull up the 2 strings hanging out from the
2 ends of Element to detach the Element.
5 Bracket Body
Element, A
1) Remove the 4 bolts and separate Bracket
Body Element, A. (Use +Screw Driver.)
