No Parts Procedure Remark
4 Bracket Body
Element, A
1) Remove the 4 bolts and separate Bracket
Body Element, A. (Use +Screw Driver.)
5 Cushion Bypass 1) Slide Cushion Bypass to the direction
seen in the picture besides.
Take caution not to break down EPS
structure.
6 Cushion Mid 1) Slide Cushion Mid to the direction seen in
the picture besides.
2) Separate the 2 temperature sensor
connectors.
Take caution not to break down EPS
structure.
To Next Page
