10-6 Samsung Electronics
Q AN035JSKLKN/AN050JSKLKN/AN080JSKLKN/AN100JSKLKN
1. Remove 2 screws on the maintenance cover.
2. Take off the maintenance cover from the ventilator.
3. Detach the 2 heat exchange elements in order.
O The heat exchange element is heavy. Take care not to drop it.
O There are 2 heat exchange elements in the ventilator.
Make sure clean them at once.
4. Remove all dust and particles on the heat exchange elements with a
nozzle of a vacuum cleaner.
O
Take care not to attach the nozzle too close.
It may damage the heat exchange element.
5. Reassemble the heat exchange elements and maintenance cover.
tDo not wash the heat exchange element. It may decrease its efficiency.
t*GUIFIFBUFYDIBOHFFMFNFOUJTEBNBHFEQVSDIBTFJUJOEJWJEVBMMZ
in a service center or an agency that you bought the product.
t.BLFTVSFUPUVSOPGGUIFTVCQPXFSTVQQMZ
Heat exchange element
Screw
