Samsung Generation 6 - Page 4

www.jouleuk.co.uk | www.joule.ie
4
Heat Pump
Commissioning Sheet
Please register your product online
Heating Controls
Ground Floor Heat
Emitter
Type of Control
Used
Serial Number
1st Floor Heat
Emitter
Type of Control
Used
Blending Valve Fitted
Type of control i.e. Underoor heating system, programmable room stat, etc.
Tank And Mim Unit Data
Tank Manufacture Model Number Serial Number
DHW Storage Solar Installed Blending Valve Fitted
Control Box
Location
Benchmark Book
Completed
Tank Sensor Fitted
Fuse Rating For
Mim Unit
Cable Size Vented or Unvented
Immersion Heater
Volts
Flow And Return
Lines Insulated
Space Heating Field Settings
Menu
Code
Function Default Site Settings
2011 Low Ambient temp for weather comp -10
2012 High Ambient temp for weather comp +15
2021 Flow temperature at low ambient point (2011) Zone 1 +40
2022 Flow temperature at high ambient point (2012) Zone 1 +25
2031 Flow temperature at low ambient point (2011) Zone 2 +50
2032 Flow temperature at high ambient point (2012) Zone 2 +35
2091
External Run input for Zone 1 ( Room stat )
(Not Use, Recommended-Use
(Signal only ON/OFF), Use(Signal ON/OFF) or WL Interlink OFF(Water Pump1)
Use(Signal ON/OFF) or WL Interlink OFF(Water Pump2)
Use(Signal ON/OFF) or WL Interlink OFF(Water Pump3)
0 (No)
2092
External Run input for Zone 2 ( Room stat )
(Not Use, Recommended-Use
(Signal only ON/OFF), Use(Signal ON/OFF) or WL Interlink OFF(Water Pump1)
Use(Signal ON/OFF) or WL Interlink OFF(Water Pump2)
Use(Signal ON/OFF) or WL Interlink OFF(Water Pump3)
0 (No)
2093 Remote Controller Room Temp Control 1
MUST BE COMPLETED AND
THEN REGISTERED ONLINE
TO COMPLETE WARRANTY
