Samsung Generation 6 - Page 5

Heat Pump Installation Guide
5
Settings for Twin Heat Pump Installation & Hybrid Systems
Menu Code Function Default Site Settings
4021 Enables control output for back up heat pump (0=No 1=Yes) 0
4024 Ambient temperature below which the slave will assist +10
4031 Tells the Master unit that a backup boiler is tted (0=No 1=Yes) 0
4032 Tells the Master unit to use the boiler as back up at the value of 4033. ( Set to 1) 0
4033 Ambient condition for the boiler to be enabled -15
Domestic Hot Water & Heat Pump Settings
Menu Code Function Default
Site
Settings
3011 Hot water cylinder tted (0= No 1=Yes) 0
3021 Heat Pump Max Temp for DHW 50
3024 Min. space heating time 5
3025 Max. cylinder heating time from heat pump before turning back to heating zones* 30
3032 Max. cylinder heating time from heat pump before turning on immersion to support it** 20
3041 Anti-Legionella function ( 0=O 1=Yes) 1
3042 Day of Anti-Legionella Function Friday
3043 Start Time of Anti Legionella function 23 Hrs
3044 Target Temp 70
3045 Hold Time at 3041 10
3051 Hotwater Boost Function (0=O 1=On) 0
3052 Hotwater Boost Timer duration x10 Min 6 (1hr)
3081 Back Up Heater ( 1st Step ) 0
3082 Back Up Heater ( 2nd Step ) 0
3083 Booster Heater Capacity 3
**30 = Domestic Hot Water Tank ( additional function )
*3025 = 200 Ltr Cylinder = 50 *3025 =300 Ltr Cylinder = 90
**3032 = 200 Ltr Cylinder = 50 **3032 =300 Ltr Cylinder = 90
Installer’s Signature
Print Name
Date
Heat Pump
Commissioning Sheet
Please register your product online
MUST BE COMPLETED AND
THEN REGISTERED ONLINE
TO COMPLETE WARRANTY
