Samsung Generation 6 - 2 x AS Heat Pump Mechanical Diagrams

www.jouleuk.co.uk | www.joule.ie
46
5
System
2x AS Heat Pump & Smart Plumb Pre-plumbed
Legend
1
Joule Smart Plumb DHW/Buer Cylinder
2
Samsung Heat Pump
3
Heating Expansion Vessel
4
28mm Y-Strainer
5a
Primary Pump Flow from Heat Pump
5b
Primary Pump Return to Heat Pump (Where Req.)
6
Flow Regulator/Flush and Fill Unit
7
28mm Buer 2 Port Zone Valve
8
28mm DHW 2 Port Zone Valve
9a
22mm 2 Port Zone Valve Heating Zone 1
9b
22mm 2 Port Zone Valve Heating Zone 2
9c
22mm 2 Port Zone Valve Heating Zone 3
10
DHW Heat Pump Stat Pocket
11
Solar Probe Stat Pocket (Where Applicable)
12
DHW Immersion
13
Buer Tank Immersion (Where Applicable)
14
Buer Tank Stat (Where Applicable)
15
DHW High Limit Stat
16
Heating Zone Circulating Pump
17
UFH Circulation Pump
18
Samsung Heat Pump Flow Switch
19
2 Pole 20A NO Relay
25
ELCB
26
Automatic Bypass Valve
Pre-plumbed Pipework Pipework to be intalled by Installer
2 Heating & 1 Domestic Hot Water
Mechanical Diagram
