Samsung Generation 6 - Smart Plumb Compact Installation; System Schematics

www.jouleuk.co.uk | www.joule.ie
54
After servicing, re-secure all cables using straps provided. Reconnect main re-
mote controller cable to its relay connector. Replace front panel and re-secure
screws at base
2 Heating & 1 Domestic Hot Water
7
System
Mechanical Schematic - 3 Zone
Smart Plumb Compact Installation
Pre-plumbed Components Pipework to be intalled by Installer
Legend
1
Joule SmartPlumb Compact Cylinder
2
Samsung Monobloc Heat Pump
3
28mm Y-Strainer
4
Flow regulator/Flush & Fill Unit
5
Automatic Air Vents
6
UFH Circulation Pump
7
Automatic Bypass Valve
8
Heating Expansion Vessel
9
Primary Circulating Pump
10
Heating System Circula- tion Pump
11
Hot Water Zone Valve
12
Heating Zone 1 Valve
13
Heating Zone 2 Valve
