Mechanical Schematic - 4 Zone
3 Heating & 1 Domestic Hot Water
7
System
Smart Plumb Compact Installation
Legend
1
Joule SmartPlumb Compact Cylinder
2
Samsung Monobloc Heat Pump
3
28mm Y-Strainer
4
Flow regulator/Flush & Fill Unit
5
Automatic Air Vents
6
UFH Circulation Pump
7
Automatic Bypass Valve
8
Heating Expansion Vessel
9
Primary Circulating Pump
10
Heating System Circula- tion Pump
11
Hot Water Zone Valve
12
Heating Zone 1 Valve
13
Heating Zone 2 Valve
14
Heating Zone 3 Valve
Pre-plumbed Components Pipework to be intalled by Installer
