Heat Pump Installation Guide
59
Measurements
84mm
625mm
595mm
64mm
595mm
1900mm
100mm
470mm 470mm
Right Side View
Front View
Left Side View
625mm
Top View
64mm
75mm
75mm
75mm
64mm
64mm
Smart Plumb Compact Installation
Transport and Handling
