Heat Pump Installation Guide
7
Heat Pump
Installation Checklist
Please register your product online
MUST BE COMPLETED AND
THEN REGISTERED ONLINE
TO COMPLETE WARRANTY
Has all air been removed from emitters?
Have all emitters been balanced correctly?
If UFH is installed, have correct owrates been set?
If UFH is installed, are all valves on manifolds/pumps fully open?
Radiator/UFH Plumbing
Is the correct size breaker used for heatpump?
Is an isolation switch installed for the heat pump and mounted on a xed structure out beside
heatpump?
Is the correct size power supply cable used for heat pump?
Are all cable protrusions avoiding condensate tray?
Is the correct communication cable installed and wired into correct terminals?
Heat Pump Wiring
Is the correct size breaker used for controller on cylinder?
Is an isolation switch installed for controller and mounted on a xed structure beside Controller?
Is the correct size power supply cable used for controller on cylinder?
Is the correct communication cable installed and wired into correct terminals?
Is the owswitch wired back into correct terminal on control panel? (Smart Plumb Compact not
applicable)
Cylinder Wiring
Is each zone/oor corresponding with the correct zone valve?
Are all heating controls powered from controller on cylinder?
Are all heating controls wired and working?
Heating Controls/Stats Wiring
