Samsung Generation 6 - Control Kit Wiring; EHS Monoblock Wiring Details

www.jouleuk.co.uk | www.joule.ie
80
Control Kit EHS Monoblock Wiring
Terminal No. Function Description
N
230V AC Neutral Output Neutral Output to DHW Immersion
L
230V AC Live Output Live Output to DHW Immersion
B1
230V AC Neutral Output Neutral Output to Backup Immersion Cable
B2
230V AC Live Output Live Output to Backup immersion Cable
B4
230V AC Live Output Live Output to Backup Boiler (1.5mm² cable)
B5
230V AC Neutral Output Neutral Output to Circulation Pump (1.5mm² cable)
B7
230V AC Neutral Output Neutral Output to DHW Zone Valve (1.5mm² cable)
B8
230V AC Live Output Live Output to Circulation Pump (1.5mm² cable)
B10
230V AC Live Output Live Output to Heating Zone Valve 1 (Brown Cable) - Where no Buer installed
B14
230V AC Live Output Live Output to Heating Zone Valve 2 (Brown Cable) - Where no Buer installed
B15
230V AC Neutral Output Neutral output to Heating Zone Valve (Blue Cable)
B17
230V AC Live Output Live Output to DHW Zone Valve (Brown Cable)
B18
230V AC Live Input Live Output to Buer Heating Zone Valve (Brown Cable)
B19
230V AC Neutral Output Neutral Output to Time Clock (1.5mm² cable)
B20
230V AC Live Output Permanent Live to Time Clock (1.5mm² cable)
B22
230V AC Live Input Switch Live back from Time Clock for Heating Zone 1
B24
230V AC Live Input Switch Live back from Time Clock for Heating Zone 2
V1
12V Input Input from Samsung Commissioning Controller
V2
12V Input Input from Samsung Commissioning Controller
F3
12V Input Wi Module Connection
F4
12V Input Wi Module Connection
V1
12V Input Input from Samsung Commissioning Controller
V2
12V Input Input from Samsung Commissioning Controller
F3
12V Input Wi Module Connection
F4
12V Input Wi Module Connection
F1
12V Comms Communication between External Heat Pump and internal PCB (CAT 5 Shielded)
F2
12V Comms Communication between External Heat Pump and internal PCB (CAT 5 Shielded)
Earths
Connected to Earth Bar
