Samsung HW-J430 - Appendix and Specifications; Product Specifications

22
APPENDIX
APPENDIX
SPECIFICATIONS
Model name
HW-J430
GENERAL
USB 5V/0.5A
Weight
Main Unit 4.69 lbs
Subwoofer 10.12 lbs
Dimensions
(W x H x D)
Main Unit 35.7 x 1.77 x 2.75 inches
Subwoofer 7.1 x 14.2 x 11.8 inches
Operating Temperature Range +41°F to +95°F
Operating Humidity Range 10 % to 75 %
AMPLIFIER
Rated Output
Power
Main Unit 80W/CH, 4 OHM, THD = 10%, 1kHz
Subwoofer 130W, 3 OHM, THD = 10%, 100Hz
S/N Ratio (Analogue Input) 65 dB
Separation (1kHz) 65 dB
* S/N ratio, distortion, separation, and usable sensitivity are based on measurements using AES (Audio Engineering
Society) guidelines.
* Nominal specification
- Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
- Weight and dimensions are approximate.
- For the power supply and Power Consumption, refer to the label attached to the product.
a Open Source License Notice
- For further information on Open Sources used in this product, please visit the website:
http://opensource.samsung.com
- To send inquiries and requests regarding open sources, contact Samsung via Email
(oss.request@samsung.com).
