Samsung HW-S60B User Manual

ENG - 20
Connecting using an Optical Cable
Pre-connection Checklist
• When both the HDMI cable and optical cable are connected, the HDMI signal is received rst.
• When you use an optical cable and the terminals have covers, be sure to remove the covers.
LED
Indicator
White On -> Off
“Digital Audio In”
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
OPTICAL OUT
Bottom of the
Soundbar
Optical Cable (not supplied)
Top of the Soundbar
1. With the TV and Soundbar turned off, connect the DIGITAL AUDIO IN (OPTICAL) port on the
Soundbar and the OPTICAL output port on the TV with the optical cable (not supplied), as shown in
the gure.
2. Turn on the Soundbar and TV.
3. Press the (Multi Function) button at the top of the Soundbar or the (Source) button on the
remote control and then select the “Digital Audio In” mode. Then the announcement, “Digital
Audio In” is output.
4. The TV sound is output from the Soundbar.

Samsung HW-S60B Specifications

General

Audio decoders	DTS 5.1, Dolby Atmos, Dolby Digital Plus
RMS rated power	200 W
Audio output channels	5.0 channels
Soundbar mode control	Yes
Number of woofer drivers	4
Number of tweeter drivers	3
Subwoofer included	-
Product color	Black
Virtual assistant	Amazon Alexa
USB direct playback	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, OGG, WAV, WMA
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Sustainability certificates	ENERGY STAR
Bluetooth codec	SBC
Wi-Fi frequency	5 GHz
Connectivity technology	Wired & Wireless
Package depth	157.48 mm
Package width	906.78 mm
Package height	124.46 mm
Package weight	4082 g
Cables included	AC, HDMI
Number of products included	1 pc(s)

Weight and Dimensions

Depth	105 mm
Width	670 mm
Height	62 mm
Soundbar weight	2700 g
