Samsung HW-S60B User Manual

ENG - 24
Connecting to a TV that supports Dolby Atmos®
Pre-connection Checklist
• Dolby Atmos® is supported in "TV ARC" or "Wi-Fi" mode.
• Make sure that the content supports Dolby Atmos®.
HDMI IN
(ARC)
DIGITAL
AUDIO IN
(OPTICAL)
HDMI
(ARC)
Connect to the HDMI IN (ARC)
or (eARC) port of your TV.
HDMI Cable
Bottom of the
Soundbar
Connect to the HDMI (ARC) port of
the Soundbar main unit.
Top of the Soundbar
LED
Indicator
White On -> Off
“TV ARC”
1. With the Soundbar and TV turned off, connect the HDMI cable as shown in the gure.
2. Turn on the Soundbar and TV.
3. TV sound is output from the Soundbar.

Samsung HW-S60B Specifications

General

Audio decoders	DTS 5.1, Dolby Atmos, Dolby Digital Plus
RMS rated power	200 W
Audio output channels	5.0 channels
Soundbar mode control	Yes
Number of woofer drivers	4
Number of tweeter drivers	3
Subwoofer included	-
Product color	Black
Virtual assistant	Amazon Alexa
USB direct playback	No
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, OGG, WAV, WMA
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
Sustainability certificates	ENERGY STAR
Bluetooth codec	SBC
Wi-Fi frequency	5 GHz
Connectivity technology	Wired & Wireless
Package depth	157.48 mm
Package width	906.78 mm
Package height	124.46 mm
Package weight	4082 g
Cables included	AC, HDMI
Number of products included	1 pc(s)

Weight and Dimensions

Depth	105 mm
Width	670 mm
Height	62 mm
Soundbar weight	2700 g
