2-3
2. Product specications
Model LE40B55*
Feature
Digital-TV, RF, 4-HDMI, 2Ext, 1Component, 1-A/V, 1USB2.0, D-sub
Brightness : 500cd/m
2
Contrast Ratio : 4000:1
Response time : 6ms
Full HDTV (1920 x 1080 pixels)
PIP(in HDMI1, 2, 3, 4, Component1, PC mode and Sub picture is available TV, Ext1/2, AV)
�
�
�
�
�
�
Specications
Item Description
LCD Panel V400H1-L05,8bits,40inch,16.7M,16:9,0 to +50,12V,DJITO, 72%,40 inch,
FHD, w/o inverter (Second Panel : LTF400HA08,SSDZAZ,8bit,40inch,1.67M,16:9,
0.461(H)*0.461(W),0 to +50,12V,SPVA 72%,40inch FHD 60Hz)
Scanning Frequency Horizontal : 60kHz ~ 73kHz (Automatic)
Vertical : 57Hz ~ 63Hz (Automatic)
Display Colors 16.7 million colors
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 885.6(H) x 498.15 (V) mm
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption <180 W ( < 0.3W, stand by )
Dimensions
39.24 x 11.81 x 27.01 inches (996.6 x 300.0 x 686.1mm)_with stand
39.24 x 3.26 x 25.25 inches (996.6 x 82.8 x 641.4mm)_without stand
Set (W x D x H)
Weight (Set) 46.74lbs (21.2 kg)
TV System Tuning Frequency Synthesize (Refer to detailed Frequency Table)
System DVB-T, PAL, SECAM, NT4.43
Sound BG, DK, NICAM, MPEG1
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio spec. - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz
Note: Anynet+, WISELINK
