Samsung LE32B55 series User Manual

5-25
5. Exploded View & Part List
5-13. LE32B55*A Parts List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
LE32B550A5WXXC LE32B550A5W,N68A/32AA5-G5K,32,LCD-TV,SPA
0.1 M0001 BN90-01919A ASSY COVER FRONT;32,LB550,EO,CHARCOAL GR 1 S.N.A
..2 T0175 BN96-09463A ASSY SPEAKER P;8ohm,4pin,10W,R:200 / L:4 1 S.A
..2 T0003 BN96-09553A ASSY COVER P-FRONT;32,LB550,EO,PC(CLR)+P 1 S.N.A
...3 T0069 BN60-00027N SPACER-FELT;L650 32,FELT,383,0.5,20 2 S.N.A
...3 T0069 BN60-00027T SPACER-FELT;L650 32,FELT,700,0.5,20 2 S.N.A
...3 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 4 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.58 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.694 S.N.A
...3 M0112 BN63-04139P COVER-FRONT;32,LB550,EO,PC(CLR)+PC(C/GRA 1 S.A
....4 BN81-00116D RESIN-TOC;PC V0,TTP01,CLR,TN-1030(NP),TH 0.656 S.N.A
....4 BN81-00265E RESIN;ToC PC, TGR02,TN-1030S, LD046,TH30 0.787 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 2.5 S.N.A
...3 CCM1 BN63-05199E COVER-SHEET;AMBER,PE,T0.08,W85mm,200M,CL 1 S.N.A
...3 BN96-06846A ASSY HOLDER P-BOSS TOP;32,L650A,,ABS,HB, 1 S.N.A
....4 BN61-03791A HOLDER-BOSS TOP;32,L650,ABS,HB,-,-,-,WH1 1 S.N.A
.....5 BN81-00116F RESIN;ABS HB,WHT,HF-0680U,W91902,-,-,- 111.65 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE, 0.77 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.05 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.2 S.N.A
...3 BN96-07658A ASSY HOLDER P-BOSS SIDE;32,L650,,PC V1 R 2 S.N.A
....4 BN61-04074C HOLDER-BOSS SIDE;AMBER 32”,PC V1 RECYCLE 1 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.08 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.04 S.N.A
...3 BN96-09562A ASSY HOLDER P-BOSS BOTTOM;32,LB610,ABS,H 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.3 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.74 S.N.A
....4 BN61-04999A HOLDER-BOSS BOTTOM;32,LB610,ABS,HB,WH12 1 S.N.A
.....5 BN81-00116F RESIN;ABS HB,WHT,HF-0680U,W91902,-,-,- 0.2 S.N.A
...3 M0175 BN96-10382B ASSY BOARD P-TOUCH FUNCTION&IR;LN40B610A 1 S.A
0.1 M0216 BN90-01936B ASSY STAND;32,LB610,CHARCOAL GRAY,GRAY N 1 S.N.A
..2 T0920 BN61-04988A GUIDE-STAND;32,B610,PC+GF 20% 1 S.N.A
...3 BN81-00204H RESIN;Trirex,3025G20 BK,ABS+PC G/F 20%,4 0.21 S.N.A
..2 M0027 BN96-09497B ASSY STAND P-BASE;32,LB650,TEMPERED GLAS 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 3 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
...3 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.95 S.N.A
...3 BN61-04841A BRACKET-STAND BOTTOM;B650 40,SECC,T2.0 1 S.N.A
...3 BN61-04855A BRACKET-SWIVEL BOTTOM;B650 40,SECC,T2.0 1 S.N.A
...3 BN61-05238A HOLDER-SWIVEL RING TOP;LB700 40,POM HB,A 1 S.N.A
...3 BN61-05248B GUIDE-STAND NECK;LB650,32,PC,C/GRAY(TP27 1 S.N.A
...3 BN61-05254A HOLDER-SWIVEL RING BOTTOM;LB700 40,POM H 1 S.N.A
...3 BN63-05530A COVER-STAND GLASS;32,LB650,GLASS,T8.0,CH 1 S.A
....4 CCM1 BN63-04755A COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6 0.56 S.N.A
...3 T0056 BN63-05537A COVER-DECORATION;UB7000 40inch,ABS,PMMA, 1 S.N.A
....4 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.01 S.N.A
