5-26
5. Exploded View & Part List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
...3 M0126 BN73-00203A RUBBER-FOOT;LB7000 46inch,CR RUBBER,T7.0 4 S.N.A
0.1 M0002 BN90-01941A ASSY COVER REAR;32,LB550,EO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 9 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 M0013 BN96-09609A ASSY COVER P-REAR;32,LB550,EO,HIPS,HB,BK 1 S.A
...3 T0069 AA63-60131N SPACER-FELT;L2,FELT,280*10,BLK,T0.5 2 S.N.A
...3 T0101 BN61-04816A BRACKET-WALL;40, B610,SECC,T1.2 4 S.N.A
...3 M0006 BN63-05363A COVER-REAR;32,B610,EO,HIPS,HB,BK500 1 S.N.A
....4 BN81-00199H RESIN;HIPS HB,BK500,HF-1690H,K2901 1.78 S.N.A
...3 T0071 BN64-01028B INLAY-TERMINAL;LB550 32,EO,PS SHEET,T0.3 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
0.1 BN91-03375A ASSY LCD-AUO;LN32B530P7FXZA,AUO 1 S.N.A
..2 M0215 BN07-00640A LCD-PANEL;T315HW02 V2 1 S.A
...3 BN81-02345A A/S-T CON T315HW02_V2;T315HW02_V2 1 S.N.A
0.1 M0112 BN91-03749A ASSY SHIELD;LE32B550A5WXXC 1 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 7 S.N.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 4 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 4 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 M2893 BN39-01099J LEAD CONNECTOR;LB5P,LB5K,UL1007#26,30P,6 1 S.A
..2 M0174 BN44-00261B IP BOARD-IP;H32F1_9DY,H32F1_9DY,0.12mA,1 1 S.A
..2 M0254 BN61-04801C HOLDER-SIDE AV;EO,HIPS,HB,BK500,1USB,1HD 1 S.N.A
...3 BN81-00199H RESIN;HIPS HB,BK500,HF-1690H,K2901 0.01 S.N.A
..2 M0115 BN61-04820A BRACKET-STAND LINK;B650-32,SECC,T1.2 1 S.N.A
..2 M0146 BN61-04980A BRACKET-PANEL TOP;B550-3 32,SECC,T1.2 2 S.N.A
..2 BN63-05259A COVER-MAIN;EO,ABS+PMMA,HB,BK23,H/GLOSSY 1 S.N.A
...3 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.015 S.N.A
..2 M0230 BN96-10076A ASSY CABLE P-FPCB LVDS;LA46A650A1,FPCB L 1 S.A
0.1 M0017 BN91-03753A ASSY CHASSIS;LE32B550A5WXXC 1 S.N.A
..2 M0014 BN94-02668A ASSY PCB MAIN;LE32B550A5WXXC 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 CN3010 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN3011 3701-001480 CONNECTOR-DSUB;15P,3R,FEMAIL,STAMPED PIN 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN8001_EU 3709-001551 CONNECTOR-CARD SLOT;68P,1.27mm,DIP,AU50U 1 S.A
...3 CN330 3711-003847 HEADER-BOARD TO CABLE;BOX,12P,1R,2mm,ANG 1 S.A
...3 CN1001 3711-005884 HEADER-BOARD TO BOARD;BOX,30P,2R,2mm,ANG 1 S.A
...3 CN330 3711-006715 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 S.N.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 CN7006 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 1 S.N.A
...3 JA333 3722-002635 JACK-PIN;3P,Sn,YEL/WHT/RED,ANGLE 1 S.A
...3 CN3002_EU 3722-002681 JACK-SCART;42P,SN,BLK 1 S.A
To Next Page
