5. Exploded View & Part List
5-18. LE37B65*A Parts List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
LE37B653T5WXXC LE37B653T5W,N68A/37BT5-G6T,37,LCD-TV,SPA
0.1 M0001 BN90-01894B ASSY COVER FRONT;37,LB650,EO,ROSE BLACK, 1 S.N.A
..2 T0175 BN96-09463C ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:60 1 S.A
..2 T0003 BN96-09487B ASSY COVER P-FRONT;37,LB650,EO,PC(CLR)+P 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 AA60-00171C SPACER-FELT;L3,FELT,460,T0.5,20 2 S.N.A
...3 T0069 BN60-00027F SPACER-FELT;L650-37,FELT,820,0.5,20 2 S.N.A
...3 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 6 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.768 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 2.6 S.N.A
...3 CCM1 BN63-05199G COVER-SHEET;AMBER,PE,T0.08,W115mm,200M,C 0.8 S.N.A
...3 M0112 BN63-05272B COVER-FRONT;37,LB650,EO,PC(CLR)+PC(ROSE 1 S.N.A
....4 BN81-00116D RESIN-TOC;PC V0,TTP01,CLR,TN-1030(NP),TH 752.4 S.N.A
....4 BN81-00116U RESIN-TOC;PC V1, TRD03,Light Rose Black, 565.4 S.N.A
...3 BN96-09507C ASSY HOLDER P-BOSS SIDE RIGHT;37,LB650,A 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE, 0.39 S.N.A
....4 BN61-04731C BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.03 S.N.A
....4 BN61-04843C HOLDER-BOSS SIDE R;37,LB650,ABS+PMMA,HB, 1 S.N.A
.....5 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.042 S.N.A
...3 BN96-09507D ASSY HOLDER P-BOSS SIDE LEFT;37,LB650,AB 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731A BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE, 0.39 S.N.A
....4 BN61-04731C BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.03 S.N.A
....4 BN61-04843D HOLDER-BOSS SIDE L;37,LB650,ABS+PMMA,HB, 1 S.N.A
.....5 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.042 S.N.A
...3 BN96-09519B ASSY HOLDER P-BOSS BOTTOM;37,LB650,ABS,H 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.4 S.N.A
....4 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 0.46 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.07 S.N.A
....4 BN61-04826B HOLDER-BOSS BOTTOM;37,LB650,ABS,HB,WH12, 1 S.N.A
.....5 BN81-00116F RESIN;ABS HB,WHT,HF-0680U,W91902,-,-,- 233.8 S.N.A
...3 M0175 BN96-10210B ASSY BOARD P-TOUCH FUNCTION&IR;LN40B650T 1 S.A
0.1 M0002 BN90-01909A ASSY COVER REAR;37,LB650,EO 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.N.A
..2 M0013 BN96-09504A ASSY COVER P-REAR;37,LB650,EO,ABS+PMMA,H 1 S.A
...3 T0069 AA63-60131N SPACER-FELT;L2,FELT,280*10,BLK,T0.5 2 S.N.A
...3 T0101 BN61-04816A BRACKET-WALL;40, B610,SECC,T1.2 4 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.99 S.N.A
...3 M0006 BN63-05278A COVER-REAR;37,LB650,EO,PMMA+ABS,HB,BK23, 1 S.N.A
....4 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 2.391 S.N.A
...3 T0071 BN64-01028A INLAY-TERMINAL;B530 (PAL-Chelsea),PS SHE 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
...3 T0069 BP60-00015D SPACER-FELT;617W,FELT,L760,T0.5,W10 1 S.N.A
