2-5
2. Product specications
Model LE32B65*
Feature
Digital-TV, RF, 4-HDMI, 2Ext, 1Component, 1-A/V, 2USB2.0(HDD Support), LAN, D-sub
Brightness : 500cd/m
2
Contrast Ratio : 8000:1
Response time : 6.5ms
Full HDTV (1920 x 1080 pixels)
PIP(in HDMI1, 2, 3, 4, Component1, PC mode and Sub picture is available TV, Ext1/2, AV)
�
�
�
�
�
�
Specications
Item Description
LCD Panel T315HW02 V3,8bit,31.5 inch,16.7M,16:9,0 to +50,12V,AMVA3,72%,31.5 inch, FHD,
4U-Lamp, w/o inverter, 120Hz(MEMC)
Scanning Frequency Horizontal : 131.52Hz ~ 139.2Hz (Automatic)
Vertical : 118kHz ~ 122kHz (Automatic)
Display Colors 16.7 million colors
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate 310MHz
Active Display
Horizontal/Vertical 698.4 (H) x 392.85 (V) mm
AC power voltage & Frequency AC 110V ~ 240V, 50/60Hz
Power Consumption <130W ( <0.3W, stand by )
Dimensions
802.9 x 239.0 x 601.0 mm_with stand
802.9 x 77.1 x 544.9 mm_without stand
Set (W x D x H)
Weight (Set) 14.2kg
TV System Tuning Frequency Synthesize (Refer to detailed Frequency Table)
System DVB-T, PAL, SECAM, NT4.43
Sound BG, DK, NICAM, MPEG1
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio spec. - MAX Internal speaker Out : Right => 10W, Left => 10W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz
Note: Anynet+, WISELINK, Internet TV
