5-86
5. Exploded View & Part List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 6 S.N.A
..2 T0524 6902-001043 BAG PE;HDPE/NITRON,T0.015/T0.5,W1200,L80 1 S.N.A
..2 T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB,17.5g 4 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.33 S.N.A
0.1 M0019 BN92-04490A ASSY LABEL;LE32B550A5WXXC 1 S.N.A
...3 M9889 BN63-01798B CLOTH-CLEAN;cloth,180,200,sea blue,ToC 1 S.N.A
...3 T0531 BN63-05372B COVER-BOTTOM;37,LB610,HIPS,HB,BK500 1 S.A
....4 BN81-00199H RESIN;HIPS HB,BK500,HF-1690H,K2901 0.05 S.N.A
...3 M0560 BN96-01800A ASSY ACCESSORY-SCREW ZIPPER;ROME32,-,-,- 1 S.N.A
....4 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.N.A
....4 ACCESSORY 6902-000683 BAG ZIPPER;LDPE,T0.05,W60,L60,TRP,-,-,4- 1 S.N.A
...3 T0074 BN59-00862A REMOCON;LCD550,TM950,EUROPE,48 1 S.A
0.1 M0019 BN92-04490A ASSY LABEL;LE32B550A5WXXC 1 S.N.A
0.1 M0003 BN92-04670A ASSY BOX;37,LB550,EO,CHARCOAL GRAY 1 S.N.A
..2 M0521 BN69-03489A BOX-SET,IN;37LB450,CB,C-01,DW1,YEL,W1470 1 S.N.A
..2 BN69-03499A BOX-SET,OUT;37LB550,CB,C-01,DW2,YEL,W117 1 S.N.A
0.1 M0113 BN92-04675A ASSY P/MATERIAL;37,LB610 1 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 6 S.N.A
..2 T0524 6902-001043 BAG PE;HDPE/NITRON,T0.015/T0.5,W1200,L80 1 S.N.A
..2 T0214 AA61-20285C HOLDER-BOX;CORAL,PP,BLACK,HB 4 S.N.A
..2 T0214 BN74-00008A TAPE-OPP MASKING;OPP-2,T0.05,W100,L800M, 1.33 S.N.A
