Samsung Electronics 3-5
Disassembly and Reassembly
3-5 CD Mecha Continued
3-5-1 Tray Disassembly
3-5-2 Main Disassembly
3-5-3 CD Main PCB Disassembly
*When removing, take extreme care not to damage the hook.
1. Open the Tray Disc AssÕy by turning the Gear-Load(%) in the direction of open,then remove the Wire-Tray(Q).
2. Remove two Tray-Stopper and tray.
1. Remove the Tray-Roulette(3) from the Tray-Disc AssÕy(4) by releasing the hook.
2. Remove the PCB-Sensor AssÕy(5) from the tray by releasing the hook.
3. Remove the Worm-Motor AssÕy())from the Tray-Disc AssÕy(4).
4. Remove the Cushion-Motor(1) from the Tray.
5. Remove the Gear-Roulette(2) from the Tray-Disc AssÕy(4) by releasing the hook.
1. Remove the Table-Chuck AssÕy(6) from the Base-Main by turning it.
2. Push the Slider-Cam(!)towards right, then lift it up to remove.
3. Remove the Gear-Tray(^) from the Base-Main by releasing the fixed hook.
4. Remove the Gear-Converter(&)from the Base-Main by releasing the fixed hook.
5. Remove the Gear-Cam(%) from the Base-Main by releasing the fixed hook.
6. Remove the Belt(@) from the Pulley-Motor AssÕy(7) & the Gear-Pulley(#).
7. Remove the Gear-Pulley(#) from the Base-Main by releasing the fixed hook.
8. Remove the Gear-Load($).
9. Remove the Gear-Synchro(*).
10. Desolder two soldering points of the CD SUB PCB, then remove it from Base-Main by
releasing the hook.
11. Remove the Pulley-Motor AssÕy(7) by releasing the hook.
12. Remove the PCB-SW AssÕy(8) by releasing the hook.
1. Remove the Lever-Lifter(9) from the Base-Main by releasing two hooks.
2. Remove four Rubber-CD(0) from the Lever-Lifter and then remove the Deck-CD().
3. Remove the Hook.
4. Remove the CD MAIN PCB with the soldering iron.
