Samsung MAX-810 - CD Deck Exploded Views and Parts

Samsung Electronics
7-7
7-4 CD Deck Exploded View and Parts List
7-4-1 Exploded View
No. Code No. Description Specification Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
AJ59-20003F
AH61-10022C
AH63-30048A
AH66-20016A
AH66-20017A
AH66-20018A
AH71-50036A
15253-503-011
AH66-90018A
AJ30-20001B
AH61-60055A
AH31-10009A
AH31-10002B
AH60-10014A
DECK-CD
CHASSIS-DECK(M)
COVER-GEAR
GEAR(A)
GEAR(B)
GEAR(C)
SHAFT-PU
CENTER-RING
TURN-TABLE(M)
PICK-UP CDP
SPRING-T/TABLE
MOTOR-SPINDLE
MOTOR-FEED
SCREW-PH(+M2*3)
CMS-P30NM6
CMSA30 POM M90-44
CMS-V30 BLK ABS
CMS-V30 M0.3 Z13 SP POM
CMS-V30 M0.3 Z13 SP POM
CMS-V30 M0.3 Z16/Z90 SP POM
CMS-V30 D3 L79 SUS420J2
ABS+GS 20% CMS-V10N
ABS+GS 20% CMS-V10N
P/U SOH-A1 ROW V-P/J
CS STS-W PI0.4 D5.7 L9.3 CMS-V10N
RF-310T-11400 43L 25V 85mA
RF-310ta 30MM NDM4RA3ETL 11.0MM
+M2X3 FE FZY W700
Exploded Views and Parts List
7-4-2 Parts List
