FIC2 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/mV,PLASTIC,
FIC3 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/mV,PLASTIC,
JIC1 1201-000358 IC-PREAMP;22291,DIP,24P,-,DUAL,-,PLASTIC
AIC1 1201-001575 IC-POWER AMP;402,SIP,14P,46MIL,SINGLE,40,PALSTIC,56V,
RIC3 1203-000110 IC-NEGA.FIXED REG.;7912,TO-220,3P,-,PLASTIC,-11.5
RIC1 1203-000242 IC-POSI.FIXED REG.;7812,TO-220,3P,-,PLASTIC,11.5/
RIC2 1203-000276 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLASTIC,4.8/5
FIC1 1204-001465 IC-VOLUME/TONE CONT.;TDA7440D,SOP,28,18.1,PLASTIC,1
AR14L 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
AR14R 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
AR15L 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
AR15R 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
RFR7 2003-000689 R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x9mm
RR4 2003-000701 R-METAL OXIDE(S);470ohm,5%,2W,AA,TP,4x12mm
AR8 2008-000122 R-FUSIBLE;100OHM,5%,1W,AA,TP,4.3X13MM
RC13 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
RC14 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
RC9 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5
AC13 2401-000871 C-AL;220uF,20%,50V,GP,-,10x16mm,5mm
RC4 2401-001886 C-AL;1000UF,20%,35V,GP,BK,16X25MM,5
RC1 2401-001942 C-AL;3300uF,20%,35V,GP,BK,18x35.5mm
RC2 2401-001942 C-AL;3300uF,20%,35V,GP,BK,18x35.5mm
RC3 2401-003116 C-AL;4700uF,20%,35V,-,BK,18X35.5,7.
RF2 3601-000304 FUSE-CARTRIDGE;250V,630mA,TIME-LAG,GLASS,5x20mm
FCW1 3710-001567 CONNECTOR-SOCKET;10P,1R,1.25mm,ANGLE,SN
FCW2 3710-001568 CONNECTOR-SOCKET;22P,1R,1.25mm,ANGLE,SN
RCW2 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRAIGHT,SN
JCW3 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
CCW1 3711-002809 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,SN
JCW1 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN
RCW4 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN
JCW2 3711-003111 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,-,BRAS
RCW1 3711-003113 CONNECTOR-HEADER;BOX,9P,1R,2.5MM,STRAIGHT,SN
TCW1 3711-004109 CONNECTOR-HEADER;3WALL,14P,1R,2mm,STRAIGHT,SN
SPK 3716-000209 TERMINAL-BLOCK;,-,-,60V,7A
AUX 3722-000377 JACK-RCA;4P/2C,3.5MM,SN,BLK,#16~22
JLPF1L AH26-10002W COIL-TRAP;BIAS-TRAP105K,BIAS-TRAP,32DB,9.0,100PF,1
JLPF1R AH26-10002W COIL-TRAP;BIAS-TRAP105K,BIAS-TRAP,32DB,9.0,100PF,1
JL2 AH26-10003C COIL-TRAP;PCHNS-5371EQJ,BIAS-TRAP,-,-,850PF,105KHZ
JL1L AH27-10001D COIL-CHOKE;5.6MH,K,Q80,-,-,-,-,-,
JL1R AH27-10001D COIL-CHOKE;5.6MH,K,Q80,-,-,-,-,-,
RL3 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
RL4 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
AL3L AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL3R AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL4L AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL4R AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
RCW1 AH39-00144A LEAD-CONNECTOR,ASS’Y;-,-,-,-,1007#22,-,-,-,5264,51088,-,-,-
HCW1 AH39-00157D CONNECT WIRE;-,-,-,H/P LINE(MAIN),1007#22/24,-,BLK,WH
OJACK 0603-001051 OPTIC TRANSMITTER;5V,6Mb/s,5m,-15dBm,660nm,20mA
OC1 2201-000381 C-CERAMIC,DISC;22NF,20%,50V,Y5V,8.0x4.0mm,5mm,TP
OC2 2201-000487 C-CERAMIC,DISC;33pF,5%,50V,SL,TP,5x3,5m
OC3 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
OLPF 2901-001139 FILTER-EMI ON BOARD;50V,.5A,-,390PF,7X2.5X5MM,TP,RADIAL
JW118 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
JW145 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
OCW 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
OIC1 AH14-10004R IC;M74HCU04,SOP,TAPE 14P
OCW AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28
WIRE AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28
AH92-00513C ASSY FRONT PCB;MAXN52,FRONT S.N.A.
AH39-00134A LEAD-PASTEN;-,-,-,-,-,-,-,DP,RING,-,1P,50MM,1007#24
ULD16 0601-001432 LED;ROUND,BLUE,3mm,455nm
ULD19 0601-001432 LED;ROUND,BLUE,3mm,455nm
UX2 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF,
UX1 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7.5MM
E1 3406-001047 SWITCH-ROTARY;5V DC,0.5mA,-,12mm
CDW1 3708-000178 CONNECTOR-FPC/FC/PIC;16P,1.25mm,ANGLE,SN
- 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT,
FCW3 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT,
CDW2 3708-000454 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STRAIGHT,
FCW4 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
HCW1 3711-001011 CONNECTOR-HEADER;BOX,5P,1R,2.5mm,STRAIGHT,SN
FCW1 3711-004420 CONNECTOR-HEADER;2WALL,10P,1R,1.25mm,ANGLE,SN
FCW2 3711-004422 CONNECTOR-HEADER;2WALL,22P,1R,1.25mm,ANGLE,SN
H/PHONE 3722-000363 JACK-PHONE;9P,6.4MM,AU,BLK,-
3809-001185 CABLE-FLAT;30V,80C,120mm,16P,1.25mm,UL2896
- 3809-001186 CABLE-FLAT;30V,80C,150mm,7P,1.25mm,UL2896
R1 AC59-60060A MODULE-REMOCON;GP1U281R,SHARP,38KHZ,-,-,-,-
VFD AH07-00022A VF DISPLAY;HNA-13MM15,17SEG,125*29,MAX-N55
UIC1 AH11-00022A MASK ROM;LC86P6548-XXXX,100P,QFP,N55,-,8BIT
UIC2 AH14-10004L IC;NJU3718,SOP,BULK
FCW4 AH39-00201A LEAD CONNECTOR-ASSY;-,1007#28,-,03P,250mm,-,-,35023-03,51004
GND AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK
MJACK1 AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK
AH61-00357A HOLDER-VFD;-,ABS 94HB,-,BLK,-,MAX-N55
AH63-00149A FILTER-VFD;-,PC,0.3T,-,-,-,-,-,MAX-N55
CD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
CD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
CD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD11 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD12 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD13 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD14 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD15 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD16 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD17 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
UQ10 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
CQ4 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
UQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
CQ2 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
CQ7 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
CQ8 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
CQ1 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
CQ3 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
CQ5 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
CQ6 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ11 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ2 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ3 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ4 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ5 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ6 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ7 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
UQ8 0504-000118 TR-DIGITAL;KSR1003,NPN,300MW,22K/22K,TO-92,TP
ULD1 0601-001232 LED;TR,LED,1PCS,130-260%
ULD10 0601-001232 LED;TR,LED,1PCS,130-260%
ULD11 0601-001232 LED;TR,LED,1PCS,130-260%
ULD2 0601-001232 LED;TR,LED,1PCS,130-260%
ULD20 0601-001232 LED;TR,LED,1PCS,130-260%
ULD21 0601-001232 LED;TR,LED,1PCS,130-260%
ULD22 0601-001232 LED;TR,LED,1PCS,130-260%
ULD23 0601-001232 LED;TR,LED,1PCS,130-260%
ULD24 0601-001232 LED;TR,LED,1PCS,130-260%
ULD30 0601-001232 LED;TR,LED,1PCS,130-260%
ULD31 0601-001232 LED;TR,LED,1PCS,130-260%
ULD4 0601-001232 LED;TR,LED,1PCS,130-260%
ULD5 0601-001232 LED;TR,LED,1PCS,130-260%
ULD7 0601-001232 LED;TR,LED,1PCS,130-260%
ULD8 0601-001232 LED;TR,LED,1PCS,130-260%
ULD12 0601-001236 LED;ROUND,AMB,3.1mm,610nm
ULD3 0601-001236 LED;ROUND,AMB,3.1mm,610nm
ULD6 0601-001236 LED;ROUND,AMB,3.1mm,610nm
ULD9 0601-001236 LED;ROUND,AMB,3.1mm,610nm
ULD14 0601-001238 LED;ROUND,RED,3.1mm,697nm
ULD15 0601-001238 LED;ROUND,RED,3.1mm,697nm
UR90 2001-000034 R-CARBON;220OHM,5%,1/4W,AA,TP,2.4X6.4MM
AR24L 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm
AR24R 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm
UR67 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm
UR69 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm
UR71 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm
UR73 2001-000037 R-CARBON(S);330ohm,5%,1/2W,AA,TP,2.4x6.4mm
UR13 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR24 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR34 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR14 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR25 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR35 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR15 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR26 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR36 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR1 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR13 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR14 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR15 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR2 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR3 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR4 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR5 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR6 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR42 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR43 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR44 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR45 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR46 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR47 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR48 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR49 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR50 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR51 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR52 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR53 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR55 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR56 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR57 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR58 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR7 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR8 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR9 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR96 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR6 2001-000295 R-CARBON;10MOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR66 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
3-4 Samsung Electronics
