UR68 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR70 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR72 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR20 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR31 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR40 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR12 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR23 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR33 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR74 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR75 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR76 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR77 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR78 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR79 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR80 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR81 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR82 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR83 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR84 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR87 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR88 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR93 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR94 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR95 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR5 2001-000435 R-CARBON;1MOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR2 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR3 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR92 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR16 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR27 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR91 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR4 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR1 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR63 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR97 2001-000552 R-CARBON;270OHM,5%,1/4W,AA,TP,2.4X6.4MM
CR11 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR17 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR28 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR37 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
CR12 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR10 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR21 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR41 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR54 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR18 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
UR29 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
UR38 2001-000802 R-CARBON;5.6Kohm,5%,1/8W,AA,TP,1.8x3.2m
UR22 2001-000850 R-CARBON;560KOHM,5%,1/8W,AA,TP,1.8X3.2MM
- 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
UR64 2001-000855 R-CARBON;560OHM,5%,1/4W,AA,TP,2.4X6.4MM
UR19 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR30 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR39 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
UR11 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR22 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
UR32 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3.2MM
CR7 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM
CR8 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM
CR9 2001-001178 R-CARBON(S);680OHM,5%,1/2W,AA,TP,2.4X6.4MM
CSR1 2103-000341 VR-SEMI;2Kohm,30%,1/10W,TOP
UC8 2201-000389 C-CERAMIC,DISC;0.022nF,5%,50V,NP0,TP,5x3,5
UC9 2201-000389 C-CERAMIC,DISC;0.022nF,5%,50V,NP0,TP,5x3,5
UC4 2201-000825 C-CERAMIC,DISC;0.027nF,5%,50V,NP0,TP,5x3,5
UC5 2201-000825 C-CERAMIC,DISC;0.027nF,5%,50V,NP0,TP,5x3,5
AC17L 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,-
AC17R 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,3.5X1.9,-
UC13 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
UC7 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
UC6 2401-000244 C-AL;100uF,20%,10V,GP,TP,6.3x7,5
UC10 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
UC11 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
UC14 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
UC15 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
UC16 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
UC2 2401-001919 C-AL;2.2uF,20%,50V,-,TP,4x7mm,5
UC3 2401-001931 C-AL;220nF,20%,50V,-,TP,4x7mm,5
UC1 2409-000123 C-EDL;47000UF,4UA,5.5V,-,BK,-,5MM
USW1 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW10 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW11 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW12 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW13 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW14 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW15 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW17 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW18 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW19 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW2 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW20 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW21 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW22 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW23 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW24 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW25 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW26 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW27 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW29 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW3 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW30 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW31 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW32 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW33 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW34 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW35 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW4 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW5 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW6 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW7 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW8 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
USW9 3404-000165 SWITCH-TACT;12V,50mA,160gf,6x6mm,SPST
UIC3 AC14-12001G IC;KA78L05,T,-
AH92-00577A ASSY PCB;MAX-N52,TAPE,DECK
AH59-20006T DECK;ADR241AMW1,-,DC12V,-,-,MAXN55,-
G3V1-F ASSY DECK CDP;MAXN25/22 S.N.A.
2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
AH39-50001X LEAD-FASTEN;RING,1007#24,200MM,BLK
AH92-00005A ASSY-PCB-CD MAIN;G3VI,CD PACK S.N.A.
NQ1502 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,TP,90-
NIC928 0904-001442 IC-DSP;9286,8Bit,QFP,80P,-,16.9344MHz,TR,CMOS,P
NIC925 1003-000179 IC-MOTOR DRIVER;KA9258D,SOP,28P,-,SINGLE,-,ST,
NIC922 1204-001286 IC-ASP;KB9223,QFP,80P,-,PLASTIC,6V,20
JW1 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW10 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW11 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW12 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW14 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW2 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW24 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW25 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW3 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW30 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW32 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW34 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW35 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW5 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW6 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW9 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
JW13 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW15 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW16 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW17 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW18 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW19 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW20 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW21 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW22 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW23 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW26 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW27 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW28 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW29 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW30 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW31 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW33 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW4 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW7 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
JW8 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
NR109 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR203 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR300 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR57L 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR57R 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR606 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
NR602 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
NR603 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
NR104 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
NR107 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
NR100 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR120 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR121 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR204 2007-000355 R-CHIP;12KOHM,5%,1/10W,DA,TP,2012
NR103 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR119 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR13 2007-000395 R-CHIP;150KOHM,5%,1/10W,DA,TP,2012
NR400 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
NR115 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
NR10 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR11 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR12 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR4 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR5 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
NR54L 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-5
