NC106 2203-000892 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,2012
NC200 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
NC667 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
NC115 2203-001137 C-CERAMIC,CHIP;68nF,+80-20%,50V,Y5V,TP,2012,-
NC104 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC52L 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC52R 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC603 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC903 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012
NC102 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
NC201 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
NC202 2203-001619 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,2012
NC203 2203-001619 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,2012
NL105 3301-000325 CORE-FERRITE BEAD;AB,3.2x2.5x1.3mm,-,-
1003-000298 IC-MOTOR DRIVER;LB1641,SIP,10P,-,-,-,ST,PLASTI
SIC1 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
SIC2 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,DOUBLE,
NXF100 2802-000211 RESONATOR-CERAMIC;16.93MHZ,0.5%,TP,10.0X5.0X10.0
SCW5 3708-001131 CONNECTOR-FPC/FC/PIC;5P,1.25mm,STRAIGHT,SN
WCW1 3708-001252 CONNECTOR-FPC/FC/PIC;16P,1mm,STRAIGHT-F,SN
SCW1 3708-001438 CONNECTOR-FPC/FC/PIC;22P,1.25mm,ANGLE,SN
NCW500 3711-000906 CONNECTOR-HEADER;BOX,3P,1R,2mm,ANGLE,SN
SCW7 3711-003379 CONNECTOR-HEADER;NOWALL,3P,1R,2.5mm,STRAIGHT,SN
AµA’ 3811-000121 WIRE-PVC CU;BCWA,300V,100MM,7/0.16MM,#26,B
BµB’ 3811-000121 WIRE-PVC CU;BCWA,300V,100MM,7/0.16MM,#26,B
NCW101 AH39-00060A LEAD CONNECTOR-ASSY;-,51015-08,51004-08,8P,300MM,1007#28
NCW102 AH39-20561P LEAD CONNECTOR-ASSY;-,5295,PHR,6P,150mm,1007#28
ND200 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND201 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND202 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
ND203 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
SZD1 0403-000352 DIODE-ZENER;UZ4.7BM,4.7V,4.4-5.0V,500mW,DO
SZD2 0403-000361 DIODE-ZENER;UZ6.2BSB,6.2V,5.99-6.24V,50
NQ1501 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,TP,160
SR1 2001-000027 R-CARBON;100OHM,5%,1/4W,AA,TP,2.4X6.4MM
NR106 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR1 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR2 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR3 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR8 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR113 2001-000977 R-CARBON;8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
NR555 2008-000140 R-FUSIBLE;2.2OHM,5%,1/2W,AA,TP,3.5X9.4MM
NC400 2202-000243 C-CERAMIC,MLC-AXIAL;33PF,5%,50V,SL,3.5X19,-,TP
NC300 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3.5x19,-
NC106 2202-000817 C-CERAMIC,MLC-AXIAL;4.7NF,20%,16V,Y5R,TP,3.5X19,-
NC117 2301-000389 C-FILM,PEF;150nF,5%,50V,TP,12.5x15x7.5,7m
NC105 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC501 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC702 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC904 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
SC14 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
NC114 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
NC301 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
NC700 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
NC701 2401-000778 C-AL;220uF,20%,10V,GP,-,6.3x11,2.5m
SC5 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
NC703 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
NC124 2401-001324 C-AL;470nF,20%,50V,GP,BK,3x5,1mm
NC204 2401-001324 C-AL;470nF,20%,50V,GP,BK,3x5,1mm
NC666 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
NC122 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC50L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC50R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC54 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55L 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NC55R 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
NL101 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL102 2701-000111 INDUCTOR-AXIAL;100uH,10%,2.5x3.4mm
NL100 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm
SL1 2701-000179 INDUCTOR-AXIAL;33uH,10%,4.2x9.8mm
NL300 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
NL301 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
NL302 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
NIC05 AC14-12001G IC;KA78L05,T,-
SCO4 AC14-12001G IC;KA78L05,T,-
PSN52E/ELS SPEAKER-SYSTEM;MAXN52RH/ELS
***** MAXN53 Parts List *****
AH26-00065A TRANS-POWER;EI74*42,-,-,115/230V,50/60HZ,-,MAX-N52
AH38-10001A WIRE-LEAD;1007#22,1500MM
AH39-10002L POWER CORD;CP2,KLCE-2F,2.15M,5239,VDE
AH39-50001X LEAD-FASTEN;RING,1007#24,200MM,BLK
AH42-20001Q ANT-LOOP;-,KS980214-01,18.5uH,CONNECTOR
AH59-00004P REMOCON—ASSY;-,-,-,22KEY,MAX-N55,SAMSUNG
AH90-10752Y ASSY-PCB-TUNER;MAX900,CE+RDS BAND
TJW100 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
TJW22 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
TJW41 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
TJW42 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
TR6 2007-000030 R-CHIP;560OHM,5%,1/10W,DA,TP,2012
TR101 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TR102 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TR103 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TR104 2007-000033 R-CHIP;0OHM,5%,1/8W,DA,TP,3216
TR19 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR45 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR47 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
TR49 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
RR2 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR24 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR43 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
TR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR21 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR22 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR46 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR48 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR50 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR53 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR54 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR56 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
TR10 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
TR20 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
TR28 2007-000457 R-CHIP;18KOHM,5%,1/10W,DA,TP,2012
TR52 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR9 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
TR35 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR36 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR40 2007-000493 R-CHIP;2.2KOHM,5%,1/10W,DA,TP,2012
TR7 2007-000518 R-CHIP;2.7KOHM,5%,1/10W,DA,TP,2012
TR11 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
TR105 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR15 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR37 2007-000586 R-CHIP;22KOHM,5%,1/10W,DA,TP,2012
TR12 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR29 2007-000686 R-CHIP;3.3KOHM,5%,1/10W,DA,TP,2012
TR23 2007-000710 R-CHIP;3.9KOHM,5%,1/10W,DA,TP,2012
TR8 2007-000822 R-CHIP;390OHM,5%,1/10W,DA,TP,2012
TR4 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR51 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
TR17 2007-000981 R-CHIP;5.6KOHM,5%,1/10W,DA,TP,2012
TR25 2007-001043 R-CHIP;56OHM,5%,1/10W,DA,TP,2012
TR27 2007-001071 R-CHIP;6.8KOHM,5%,1/10W,DA,TP,2012
TR38 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TR44 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
TC41 2203-000239 C-CERAMIC,CHIP;0.1nF,5%,50V,NP0,TP,2012
RC2 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC20 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC28 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC29 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC3 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC44 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
TC7 2203-000429 C-CERAMIC,CHIP;0.018nF,5%,50V,NP0,TP,2012
TC1 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC5 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC99 2203-000609 C-CERAMIC,CHIP;22nF,10%,50V,X7R,TP,2012
TC33 2203-000844 C-CERAMIC,CHIP;39nF,10%,50V,X7R,TP,2012,-
RC7 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC10 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC13 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC15 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC35 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC45 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
TC6 2203-000979 C-CERAMIC,CHIP;47nF,10%,50V,X7R,TP,2012
RC8 2203-001058 C-CERAMIC,CHIP;0.56nF,5%,50V,NP0,TP,2012
TC61 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012
TC62 2203-001105 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,2012
TC32 2203-001132 C-CERAMIC,CHIP;0.68nF,5%,50V,NP0,TP,2012
TC2 2203-001517 C-CERAMIC,CHIP;0.015nF,5%,50V,NP0,TP,2012
RC4 2203-001524 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,2012
RC5 2203-001524 C-CERAMIC,CHIP;0.047nF,5%,50V,NP0,TP,2012
TC63 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
TC64 2203-001551 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,TP,2012
TC50 2203-001611 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,2012
TC51 2203-001611 C-CERAMIC,CHIP;0.022nF,5%,50V,NP0,TP,2012
TD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,TP
TZD1 0403-000367 DIODE-ZENER;UZ7.5BSC,7.5V,7.33-7.64V,500mW
RZD1 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
TZD2 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1W,DO-41
TQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92,TP,12
TQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ3 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250mW,TO-92,-,70-
TQ1 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TQ7 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,TP,120-
TR30 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4X6.4MM
RR1A 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
TR44 2001-000118 R-CARBON(S);180ohm,5%,1/2W,AA,TP,2.4x6.4mm
TR58 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
TR5 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
3-12 Samsung Electronics
