AC9R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC10L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC10R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC9L 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
FC9R 2301-000375 C-FILM,PEF;100nF,5%,50V,TP,11x12.5x6.5,7m
JC26 2301-000404 C-FILM,PEF;2.2NF,10%,50V,TP,5.5X7X3.2MM,5
JC27 2301-000404 C-FILM,PEF;2.2NF,10%,50V,TP,5.5X7X3.2MM,5
JC22L 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM
JC22R 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM
JC29 2301-000407 C-FILM,PEF;2.7NF,10%,50V,TP,5.5X7X3MM,5MM
JC17L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC17R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC4L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC4R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC8L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC8R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,5
JC18L 2301-000422 C-FILM,PEF;3.3NF,10%,50V,TP,5.5X7X3MM,5MM
JC18R 2301-000422 C-FILM,PEF;3.3NF,10%,50V,TP,5.5X7X3MM,5MM
FC8L 2301-000454 C-FILM,PEF;5.6NF,10%,50V,TP,6X12X3,3.5MM
FC8R 2301-000454 C-FILM,PEF;5.6NF,10%,50V,TP,6X12X3,3.5MM
JC19L 2301-000462 C-FILM,PEF;6.8NF,10%,50V,TP,6X12X3,3.5MM
JC19R 2301-000462 C-FILM,PEF;6.8NF,10%,50V,TP,6X12X3,3.5MM
JC9 2401-000240 C-AL;100uF,20%,10V,GP,TP,5x11,5
AC6 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC8 2401-000357 C-AL;100UF,20%,50V,GP,-,8X11.5,3.5M
AC4L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
AC4R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
AC897 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC19 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC50 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
FC9 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC12L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC12R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC20L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC20R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC21L 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC21R 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
JC7 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
RC7 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
RC8 2401-000438 C-AL;10uF,20%,25V,GP,-,5x11,2mm
JC11 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
AC3L 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM
AC3R 2401-001164 C-AL;33UF,20%,16V,GP,-,5X11,2MM
JC14L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
JC14R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
JC31 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
JC3L 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
JC3R 2401-001465 C-AL;47UF,20%,10V,GP,-,5X11,2MM
- 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
RC12 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
RC19 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
FC2L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC2R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC3L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC3R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC4L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC4R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC5L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC5R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
RC8 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC14L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC14R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC15 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC18 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
JC10 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
JC5L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
JC5R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
RC10 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
FC11 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC25 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
JC28 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
FC16 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC6L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC6R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC7L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
FC7R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC13L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC13R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC15L 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
JC15R 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RC11 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RC5 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RC6 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
RL2 2701-000178 INDUCTOR-AXIAL;33uH,10%,3x7mm
JL1 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
RL1 2701-000298 INDUCTOR-AXIAL;470uH,10%,4.2x9.8mm
- 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
RF2*2 3602-000147 FUSE-CLIP;250V,7.5A,30MOHM
AL2L 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,1/0.5MM,-,-
AL2R 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4MM,1/0.5MM,-,-
RD4 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41,TP
RD10 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP
RD11 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP
RD12 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP
RD13 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,TP
RBD1 0402-001258 DIODE-BRIDGE;GBU606,600V,6A,SIP-4,BK
RQ1 0502-000424 TR-POWER;2SB1566-F,PNP,2W,TO-220FN,BK,1
0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN,BK,1
RQ6 0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN,BK,1
RQ9 0502-000425 TR-POWER;2SD2395-F,NPN,2W,TO-220FN,BK,1
FIC2 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/mV,PLASTIC,
FIC3 1201-000163 IC-OP AMP;4560,SOP,8P,173MIL,DUAL,100V/mV,PLASTIC,
JIC1 1201-000358 IC-PREAMP;22291,DIP,24P,-,DUAL,-,PLASTIC
AIC1 1201-001582 IC-POWER AMP;402-070,SIP,15P,-,DUAL,30dB,PLASTIC,44V,
RIC3 1203-000110 IC-NEGA.FIXED REG.;7912,TO-220,3P,-,PLASTIC,-11.5
RIC1 1203-000242 IC-POSI.FIXED REG.;7812,TO-220,3P,-,PLASTIC,11.5/
RIC2 1203-000276 IC-POSI.FIXED REG.;7805,TO-220,3P,-,PLASTIC,4.8/5
FIC1 1204-001465 IC-VOLUME/TONE CONT.;TDA7440D,SOP,28,18.1,PLASTIC,1
- 13954-500-210 CERAMIC-PIPE;PI1.4 7MM 1
AR14L*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
AR14R*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
AR15L*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
AR15R*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
AR8*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
RD10*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
RD11*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
RD12*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
RD13*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
RD4*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
RFR7*2 13954-500-210 CERAMIC-PIPE;PI1.4 7MM
AR14L 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
AR14R 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
AR15L 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
AR15R 2003-000390 R-METAL OXIDE(S);0.27OHM,5%,2W,AA,TP,4X12MM
RFR7 2003-000689 R-METAL OXIDE(S);4.7ohm,5%,1W,AA,TP,3.3x9mm
RR4 2003-000701 R-METAL OXIDE(S);470ohm,5%,2W,AA,TP,4x12mm
AR8 2008-000122 R-FUSIBLE;100OHM,5%,1W,AA,TP,4.3X13MM
RC13 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
RC14 2201-000546 C-CERAMIC,DISC;4.7NF,20%,400V,Y5U,BK,16X7,10
RC9 2401-000230 C-AL;100uF,20%,100V,GP,TP,12.5x20,5
AC13 2401-000871 C-AL;220uF,20%,50V,GP,-,10x16mm,5mm
RC1 2401-001067 C-AL;3300UF,20%,42V,GP,-,18X35.5,7.
RC2 2401-001067 C-AL;3300UF,20%,42V,GP,-,18X35.5,7.
RC4 2401-001886 C-AL;1000UF,20%,35V,GP,BK,16X25MM,5
RC3 2401-003116 C-AL;4700uF,20%,35V,-,BK,18X35.5,7.
RF2 3601-000162 FUSE-CARTRIDGE;250V,1.25A,TIME-LAG,GLASS,5x20mm
FCW1 3710-001567 CONNECTOR-SOCKET;10P,1R,1.25mm,ANGLE,SN
FCW2 3710-001568 CONNECTOR-SOCKET;22P,1R,1.25mm,ANGLE,SN
RCW2 3711-000190 CONNECTOR-HEADER;1WALL,2P,1R,7.92MM,STRAIGHT,SN
JCW3 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
CCW1 3711-002809 CONNECTOR-HEADER;BOX,8P,1R,2mm,STRAIGHT,SN
JCW1 3711-003107 CONNECTOR-HEADER;BOX,3P,1R,2.5mm,STRAIGHT,SN
JCW2 3711-003111 CONNECTOR-HEADER;BOX,6P,1R,2.5mm,-,BRAS
RCW1 3711-003113 CONNECTOR-HEADER;BOX,9P,1R,2.5MM,STRAIGHT,SN
TCW1 3711-004109 CONNECTOR-HEADER;3WALL,14P,1R,2mm,STRAIGHT,SN
SPK 3716-000209 TERMINAL-BLOCK;,-,-,60V,7A
AUX 3722-000377 JACK-RCA;4P/2C,3.5MM,SN,BLK,#16~22
JLPF1L AH26-10002W COIL-TRAP;BIAS-TRAP105K,BIAS-TRAP,32DB,9.0,100PF,1
JLPF1R AH26-10002W COIL-TRAP;BIAS-TRAP105K,BIAS-TRAP,32DB,9.0,100PF,1
JL2 AH26-10003C COIL-TRAP;PCHNS-5371EQJ,BIAS-TRAP,-,-,850PF,105KHZ
JL1L AH27-10001D COIL-CHOKE;5.6MH,K,Q80,-,-,-,-,-,
JL1R AH27-10001D COIL-CHOKE;5.6MH,K,Q80,-,-,-,-,-,
RL3 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
RL4 AH27-10001F COIL-CHOKE;27UH,K,Q30,-,-,DR(6.5*7.5),-,-,
AL3L AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL3R AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL4L AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
AL4R AH27-90001A COIL-SPRING;,2.2UH,-,-,SPRING
RCW1 AH39-00144A LEAD-CONNECTOR,ASS’Y;-,-,-,-,1007#22,-,-,-,5264,51088,-,-,-
HCW1 AH39-00157D CONNECT WIRE;-,-,-,H/P LINE(MAIN),1007#22/24,-,BLK,WH
GND AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK
RC1 AH39-50001L LEAD-FASTEN;RING,1007#24,200MM,BLK
OJACK 0603-001051 OPTIC TRANSMITTER;5V,6Mb/s,5m,-15dBm,660nm,20mA
OC1 2201-000381 C-CERAMIC,DISC;22NF,20%,50V,Y5V,8.0x4.0mm,5mm,TP
OC2 2201-000487 C-CERAMIC,DISC;33pF,5%,50V,SL,TP,5x3,5m
OC3 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
OLPF 2901-001139 FILTER-EMI ON BOARD;50V,.5A,-,390PF,7X2.5X5MM,TP,RADIAL
JW118 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
JW145 3301-000297 CORE-FERRITE BEAD;AA,3.6x1.2x5.7mm,1400,2900G
OCW 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2mm,STRAIGHT,SN
OIC1 AH14-10004R IC;M74HCU04,SOP,TAPE 14P
OCW AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28
WIRE AH39-00023A LEAD CONNECTOR-ASSY;-,51004-03,51004-03,03P,300MM,2547#28
AH92-00513C ASSY FRONT PCB;MAXN52,FRONT S.N.A.
AH39-00134A LEAD-PASTEN;-,-,-,-,-,-,-,DP,RING,-,1P,50MM,1007#24
ULD16 0601-001432 LED;ROUND,BLUE,3mm,455nm
ULD19 0601-001432 LED;ROUND,BLUE,3mm,455nm
UX2 2801-001394 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAY,12.5pF,
UX1 2802-000181 RESONATOR-CERAMIC;6MHZ,0.3%,BK,9.0X4.0X7.5MM
E1 3406-001047 SWITCH-ROTARY;5V DC,0.5mA,-,12mm
CDW1 3708-000178 CONNECTOR-FPC/FC/PIC;16P,1.25mm,ANGLE,SN
- 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT,
FCW3 3708-000449 CONNECTOR-FPC/FC/PIC;7P,1.25MM,STRAIGHT,
CDW2 3708-000454 CONNECTOR-FPC/FC/PIC;22P,1.25MM,STRAIGHT,
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 3-15
