Samsung MAX-VN52 - Installingyourmini-Compactsystem; Front Panel View

GB
4
1. Disc Selection buttons
2. Compact Disc Compartment
3. Timer/Clock
4. Timer On/Off
5. On/Standby
6. Demo
7. AI Off/Sleep
8. Memory
9. Mono/ST (NTSC/PAL)
10. Mic Mixing
11. Headphone Jack Connector
12. MIC 1, 2
13. Rec Lock
14. Cassette Deck 1
15. Rec/Pause
16. Echo
17. Program
18. Repeat
19. CD Synchro
20. Tuning Mode or Stop button
21. CD Track or radio station search (Down/Up)
22. TAPE Normal Recording
23. TAPE Hi-Speed Recording
24. Rev mode
25. Deck 1/2
26. Cassette Deck 2
27. EQ
28. S.Bass
29. Power Sound/Surround
30. Multi Jog
31. Return
32. Menu On/Off
33. Shuffle
34. Volume
35. Function Selection buttons
36. Open/Close
37. Disc Change
Front Panel View
