Samsung ME55A - User Manual

Samsung ME55A
221 pages
Save Page as PDF
Print Icon
To Next Page IconTo Next Page
To Next Page IconTo Next Page
Loading...
BN46-00098A-02
User Manual
ME40A
ME46A
ME55A
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.

Table of Contents

Questions and Answers

  • O
    oleeJul 30, 2025
    Why does my Samsung ME55A Monitor display not appear on the system information chart?
    • B
      Bradley GeorgeJul 31, 2025
      If the display you're trying to control isn't showing up on the system information chart for your Samsung Monitor, here are a few things to check: * Make sure the RS232C cable is properly connected to the correct serial port. * Ensure that no other display is connected with a duplicate ID, as this can cause data collision. * Verify that the display ID is within the range of 0 to 99. You can change the ID in the Display menu.
  • S
    Sandra YoungAug 10, 2025
    What to do if the Samsung Monitor display doesn't appear on the Control Info Grids?
    • R
      Rachel HallAug 10, 2025
      If the display you want to control does not appear on the other Control Info Grids of your Samsung Monitor, make sure that the display is powered on (check the power status in the system information chart) and that you have selected the input source the display is connected to.
  • A
    Alex EllisAug 19, 2025
    How to synchronize power on/off times on Samsung Monitors?
    • K
      Kyle NicholsSep 12, 2025
      If your Samsung Monitor displays are powering on or off at different times, even though the On Time or Off Time is set, adjust the time on your PC to synchronize the time between the connected displays.

Summary

Preparations

Installation and Mounting Guidelines

Guidelines for product installation, including wall mounting, tilting, and ventilation.

Connecting Source Devices

PC Connectivity and Settings

Instructions for connecting a PC via various cable types and adjusting display settings.

Using MDC for Multi-Device Control

MDC Connection Methods

Explains how to connect to MDC via RS232C or RJ45 and configure ID settings for control.

MDC Operations and Features

Device Connection and Management

Details on connecting devices to MDC, managing connections, and setting device IDs.

Screen Adjustment

Picture Mode Selection

Guides on selecting and adjusting picture modes based on input source and viewing environment.

Advanced Picture Controls

Covers detailed adjustments for picture size, position, resolution, contrast, brightness, and color settings.

Sound Adjustment

Sound Modes and Effects

How to select sound modes, apply effects, and use the equalizer for optimal audio output.

Media Playback Features

Playing Media Files (Video, Photo, Music)

Guides on playing video, photo, and music files, including USB playback and playlist creation.

Network Setup

Wired Network Connections

Wireless Network Setup

Guides on connecting to wireless networks via Auto Setup, Manual Setup, WPS, and Ad Hoc modes.

System Settings

Plug & Play and Time Configuration

Screen Protection and Video Wall

MagicInfo Lite Player

Schedule Management

Troubleshooting Guide

Pre-Contact Support Checks

Steps for diagnosing issues and testing the product before contacting customer service.

Frequently Asked Questions (Q&A)

Answers to common user questions regarding frequency, resolution, and power-saving settings.

Samsung ME55A Specifications

General IconGeneral
Pixel pitch0.21 x 0.21 mm
Response time8 ms
Display diagonal55 \
Display brightness380 cd/m²
Vertical scan range48 - 75 Hz
Horizontal scan range30 - 81 kHz
Contrast ratio (dynamic)-
Contrast ratio (typical)5000:1
Display number of colors1.073 billion colors
Supported graphics resolutions1920 x 1080 (HD 1080)
3DNo
Aspect ratio16:9
Flash memory850 MB
Composite syncYes
Headphone outputs1
Voltage tolerance10 %
Internal memory typeDDR3
Headphone connectivity3.5 mm
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
DVI-D ports quantity2
DVI-I ports quantity0
Product colorBlack
Product designDigital signage flat panel
Panel mounting interface400 x 400 mm
RMS rated power20 W
Cables includedVGA
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)1 W
Power consumption (typical)180 W
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Processor frequency0.8 GHz
Computer system typeThin client
Package depth199 mm
Package width1364 mm
Package height848 mm
Package weight22200 g
CertificationFCC, CE, VCCI, KCC, BSMI, C-Tick, CCC, UL, CSA, TUV, NEMKO, KC, PSB, GOST, SIQ, PCBC, NOM, IRAM, SASO
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth29.9 mm
Width1246.4 mm
Height718.2 mm
Weight17100 g
