9-6Samsung Electronics
Circuit Descriptions
■ MH068FXEA4 /MH080FXEA4
ex) 4 Rooms(MH026FPEA+MH026FPEA+MH035FPEA+MH052FPEA✳)
Inverter
Compressor
Main-
accumulator
Sub-
accumulator
1/2"
3/8"
1/2"
Service valve
(5/8")
Header
(5/8")
Distributor
3/8"
3/8"
3/8"
1/2"
Service v/v
(3/8")
Receiver
1/2"
1/4"
1/4"
1/4"
1/4"
EEV
1
2
3
4
OUTDOOR UNIT INDOOR UNIT
ROOM A
ROOM B
ROOM C
ROOM D
