Disassembly and Reassembly
Samsung Electronics4-6
No Parts Procedure Remark
2) Detach the Room Sensor.
3) Detach the Holder Pipe at the rear side
of the unit.
4) Loosen 3 fixing screws of left Holder
Evap.
5) Loosen 1 fixing screw of right Holder
Motor.
6) Detach the Heat Exchanger from the
indoor unit.
24296A(1)_1 11/11/05 5:03 PM Page 4-6
To Next Page
