Disassembly and Reassembly
4-15Samsung Electronics
No Parts Procedure Remark
5
6
Drain Panel Sub
Evap
1) Detach Ass'y Drain Panel Sub after
loosen 2 fixing screws both side of it.
1) Loosen 3 fixing screws of Ass'y Evap
around.
2) Loosen 2 fixing screws as shown in
picture and detach Ass'y Cabinet-Side
LF B.
