4-10Samsung Electronics
Disassembly and Reassembly
No Parts Procedure Remark
6) Loosen 4 fixing screw and pull up the
Control Box.
7) Loosen 12 fixing screws and detach the
Cabinet Side.
8) Detach the Terminal Cover and detach
the comp lead wire.
[MH070FXEA4A/MH080FXEA4A model only]
To Next Page
