Service Manual
Alignment and Adjustments
4-12
1. Open and close the front cover. The jammed paper
is automatically ejected from the printer.
2. Gently pull the jammed paper out of the output tray.
If you do not see the jammed paper or if there is
any resistance when you pull, stop pulling and go to
the next step.
3. Open the top cover and inner cover.
Caution : • When removing the jammed paper, be
careful not to touch the heat roller
(located underneath the inner cover). It
is hot and could cause burns!
• The top and inner cover themselves
may also be hot due to the heat roller.
Allows the printer to cool before
opening the covers.
4.6.1 Clearing Paper Jams
Occasionally, paper can be jammed during a print job. Some of causes include:
• The tray is overfilled.
• The front cover has been opened during a print job.
• Paper that does not meet paper specifications has been used.
• Paper that is outside of the supported size range has been
If a paper jam occurs, the On Line/Error LED on the control panel lights red. Find and remove the jammed paper.
If it is invisible, look inside the printer.
4.6.2 In the Paper Exit Area

Samsung ML-2571N Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Processor model	Samsung
Built-in processor	Yes
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Custom media sizes	(76 x 127mm) - (216 x 356mm)
Networking features	Ethernet 10/100Base-TX
Compatible operating systems	Windows 98/Me/NT4.0/2000/XP Windows 2003 Server Red Hat 8-9 Fedora Core 1-3 Mandrake 9.2-10.1 SuSE 8.2-9.2 Mac OS 8.6-9.2 Mac OS 10.1-10.4
Number of print cartridges	1
Total input capacity	250 sheets
Total output capacity	100 sheets

Weight and Dimensions

Dimensions (WxDxH)	352 x 299 x 242 mm
