Troubleshooting
6-8
6.3 Malfunction
6.3.1 All LEDs blinking (Fuser Error)
• Description
1. All the lamps on the operator panel blink.
2. Gear of the fuser does not work and breaks away melt away.
When printing, motor breaks away from its place due to defective fuser gear.
Check and Cause Solution
1. Check if the thermostat, AC wire and Heat Lamp is
open.
2. Check if the thermistor sensor is in place.
3. Check if the heat lamp works properly.
4. Check if the overheat circuit works properly.
5. The fuser gear is defective due to melting away.
1. If the thermostat is open replace the fuser and
check following items.
2. If the thermistor sensor device is located deep in the
sponge, replace the fuser.
3. Check if the circuit of overheat mode works properly.
4. Run DCU mode : Perform DCU diagnostic code 10.
5. Replace Fuser.
6.3.2 All LEDs blinking (Scan Error)
• Description
1. All lamps on the operator panel blink.
Check and Cause Solution
DCU Mode : Perform DCU diagnostic code 05. If the DCU
error code 95 is displayed, replace LSU.
Replace LSU.
If you cannot solve the problem after you replace LSU,
replace the main board.

Samsung ML-2571N Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	24 ppm
Processor model	Samsung
Built-in processor	Yes
Sound power level (standby)	35 dB
Sound pressure level (printing)	53 dB
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Custom media sizes	(76 x 127mm) - (216 x 356mm)
Networking features	Ethernet 10/100Base-TX
Compatible operating systems	Windows 98/Me/NT4.0/2000/XP Windows 2003 Server Red Hat 8-9 Fedora Core 1-3 Mandrake 9.2-10.1 SuSE 8.2-9.2 Mac OS 8.6-9.2 Mac OS 10.1-10.4
Number of print cartridges	1
Total input capacity	250 sheets
Total output capacity	100 sheets

Weight and Dimensions

Dimensions (WxDxH)	352 x 299 x 242 mm
