To Next PageTo Next PageWhat to do if Samsung Microwave Oven does not accept key input?
If your Samsung Microwave Oven isn't accepting key inputs, consider the following: * Ensure the key input is in the correct sequence. * Check for open or loose connections between the membrane keypad and the Ass'y PCB. * Inspect the membrane panel for shorts or opens. * A defective Ass'y PCB could be the cause. Replace PCB main.
Why Samsung Microwave Oven does not operate and return to the plugged in mode?
If your Samsung Microwave Oven isn't operating and returns to the plugged-in mode, the Ass'y PCB might be defective. Replace PCB main.
How to fix the turntable motor that does not rotate in Samsung Microwave Oven?
If the turntable motor in your Samsung Microwave Oven isn't rotating, here are a couple of things to check: 1. Inspect the turntable motor wiring for any opens or looseness. 2. The turntable motor itself might be defective. Replace turntable motor.
What to do if Samsung MR1032UBC can program but timer does not start?
If your Samsung Microwave Oven can be programmed, but the timer doesn't start, it could be due to: 1. Open or loose wiring of the latch switch. 2. Off-alignment of the latch switch. 3. A defective latch switch. Adjust the door and interlock switches.
Why is my Samsung MR1032UBC making a loud buzzing noise?
If your Samsung Microwave Oven is making a loud buzzing noise, here's what you can check: * Tighten the screws on the fan motor. * Tighten the screws on the H.V. Transformer. * Replace the H.V. Diode.
Why is my Samsung Microwave Oven taking longer to cook food?
If your Samsung Microwave Oven isn't heating food properly and takes longer to cook, there could be a few reasons: 1. Check if the power source voltage has decreased. 2. Inspect the magnetron filament circuit for any loose wiring, which can cause intermittent oscillation. 3. The magnetron might be aging. Consult an electrician.
Why does my Samsung Microwave Oven stop during cooking?
If your Samsung Microwave Oven stops operating during cooking, here are a few things to check: 1. Inspect the latch switch wiring for any looseness or breaks. Adjust the door and latch switches. 2. The thermal cutout (on the Magnetron) might be in operation.
What to do if Samsung MR1032UBC has no display and the fuse is blown?
If your Samsung Microwave Oven has no display and no operation at all, and the fuse is blown, here are some potential causes: 1. A shorted lead wire harness. 2. A defective latch switch. Check the adjustment of the latch switch and power relay. 3. A shorted HV Capacitor. 4. A shorted HV Transformer.
Why Samsung MR1032UBC Microwave Oven is dead, with no display?
If your Samsung Microwave Oven has no display and no operation at all, even though the fuse is okay, it could be due to: 1. An open or loose lead wire harness. 2. An open thermal cutout (Magnetron). Check the fan motor when the thermal cutout is defective. 3. An open low voltage transformer. 4. A defective Ass'y PCB. Check Ass'y PCB when LVT is defective.
Why is my Samsung Microwave Oven sparking?
If your Samsung Microwave Oven is sparking, it's likely due to: 1. Metallic ware or cooking dishes touching the oven wall. 2. Ceramic ware trimmed with gold or silver powder. Do not use any type of cookware with metallic trimming.
General| Type | Countertop |
|---|---|
| Power Output | 1000 Watts |
| Turntable | Yes |
| Turntable Diameter | 12.4 inches |
| Preset Cooking Programs | Yes |
| Color | Black |
General safety precautions for servicing microwave ovens, including compliance and emission checks.
Specific safety measures for servicing microwave ovens, especially regarding high voltage.
Detailed warnings and procedures for handling high voltage components during service.
A table listing key technical specifications of the microwave oven.
Description and layout of the microwave oven's control panel buttons and functions.
Illustrations and labels for external components and dimensions of the microwave.
Step-by-step guide for replacing the magnetron, fan motor assembly, and oven lamp.
Instructions for installing the microwave oven into a cabinet structure.
Procedure for safely replacing the high voltage transformer, including capacitor discharge.
Detailed steps for removing various door components like Door C, Door E, and Key Door.
Guidance on reassembling the door and performing tests to prevent microwave leakage.
Procedure for replacing the fuse, including checks on related interlock switches.
Steps to remove and replace the turntable drive motor and its coupler.
Instructions for replacing the control box, PCB assembly, and window display/membrane panel.
Checking resistance values of the high voltage transformer terminals.
Procedure for checking continuity of the low voltage transformer on the PCB.
Continuity checks for the magnetron filament and case to diagnose issues.
Methods for checking the continuity and resistance of the high voltage capacitor.
Procedure for measuring the front-to-back resistance of the high voltage diode.
Instructions for isolating and checking the continuity of main and power control relays.
Detailed procedures for adjusting interlock, door sensing, and monitor switches for proper door closure.
Procedure for measuring magnetron output power using a water temperature rise test.
Step-by-step guide for measuring microwave leakage using a survey meter and spacer cone.
Procedure for checking microwave leakage after component replacement or repair.
Important notes and precautions to ensure accurate microwave leakage measurements.
Guidelines for recording leakage measurements and calibrating the survey meter.
Common electrical issues, their causes, and recommended corrections for the microwave oven.
Diagrams showing the exploded views of the microwave oven's internal and external components.
A detailed list of main components with their code numbers, descriptions, and specifications.
List of specific parts related to the control panel and door assembly.
List of standard hardware and common parts used in the microwave oven assembly.
Schematic diagram of the main Printed Circuit Board (PCB) with component layout.
A detailed list of components and their specifications found on the PCB.
Complete schematic diagram illustrating the electrical connections and components of the oven.
