Samsung MR7491G User Manual (English)

Questions and Answers:

R
Robert JacksonAug 19, 2025
What to do if Samsung MR7491G Microwave Oven timer starts but no heat?
- D
  Donald AndersonAug 19, 2025
  If your Samsung Microwave Oven timer starts counting down, but there's no microwave oscillation (no heat, but the oven lamp and fan motor turn on), it could be due to several reasons: * Misalignment of latch switches. * Open or loose connection of the high voltage circuit, especially the magnetron filament circuit. * Defective high voltage components such as the H.V.Transformer, H.V.Capacitor, H.V.Diode, or Magnetron. * Open or loose wiring of the power relay. * Defective primary latch switch. * Defective power relay or Ass'y PCB. Adjust the door and latch switches. Check the high voltage components according to the component test procedure and replace them if defective. You may also need to replace the PCB main.
B
Brian PalmerAug 21, 2025
Why Samsung Microwave Oven does not accept key input?
- R
  Ricky LopezAug 21, 2025
  If your Samsung Microwave Oven does not accept key input (program), it could be due to: * Key input is not in sequence. * Open or loose connection of the membrane key pad to Ass'y PCB. * Shorted or open membrane panel. * Defective Ass'y PCB. Refer to the operation procedure. Replace the PCB main.
G
Gregory PerkinsAug 25, 2025
Why does Samsung MR7491G stop in the middle of cooking?
- P
  pmartinezAug 25, 2025
  If your Samsung Microwave Oven stops operating during cooking, it could be due to: * Open or loose wiring of the primary interlock switch. * Operation of thermal cutout (Magnetron). Adjust the door and latch switches.
M
Michael WestAug 26, 2025
Why Samsung MR7491G Microwave Oven can program but timer doesn't start?
- C
  chelsea53Aug 26, 2025
  If your Samsung Microwave Oven can be programmed, but the timer does not start, it could be due to: * Open or loose wiring of the secondary interlock switch * Off-alignment of the primary interlock * Defective secondary interlock S/W Adjust the door and interlock switches.
K
Kimberly HallAug 28, 2025
Why is the turntable motor not rotating in my Samsung MR7491G?
- D
  Deborah JohnsonAug 28, 2025
  If the turntable motor in your Samsung Microwave Oven does not rotate, it could be due to: * Open or loose wiring of the turntable motor. * Defective turntable motor. Check the wire of the turntable motor and replace the turntable motor if necessary.
B
Barbara SandersAug 30, 2025
Why is my Samsung MR7491G Microwave Oven sparking?
- J
  John PalmerAug 30, 2025
  If your Samsung Microwave Oven is sparking, it's likely due to metallic ware or cooking dishes touching the oven wall, or ceramic ware trimmed with gold or silver powder. Avoid using any type of cookware with metallic trimming.
A
Allison SnyderSep 1, 2025
How to fix uneven cooking in Samsung MR7491G Microwave Oven?
- S
  Susan GarciaSep 1, 2025
  If your Samsung Microwave Oven cooks food unevenly, it's due to the uneven intensity of the microwaves. Wrap thinner parts of the food with aluminum foil. Use plastic wrap or cover with a lid. Stir once or twice while cooking foods such as soup, cocoa, or milk.
M
Mallory FlowersSep 3, 2025
Why does Samsung MR7491G Microwave Oven take longer to cook?
- M
  Mario HudsonSep 4, 2025
  If your Samsung Microwave Oven has low microwave output, causing it to take longer to cook food, it could be due to: 1. A decrease in power source voltage. 2. An open or loose wiring of the magnetron filament circuit (intermittent oscillation). 3. Aging of the magnetron. Consult an electrician to check the power source voltage.
C
Chad CoxSep 6, 2025
What to do if Samsung MR7491G has no display and the fuse is blown?
- D
  David SantanaSep 6, 2025
  If your Samsung Microwave Oven has no display and no operation at all, and the fuse is blown, it could be due to: * Shorted lead wire harness * Defective primary latch switch * Defective monitor switch * Shorted HVCapacitor * Shorted HVTransformer Check the adjustment of the primary, interlock monitor, power relay, and door sensing switch.
B
Brett GonzalezSep 7, 2025
Why does the fan motor turn on when Samsung MR7491G Microwave Oven is plugged in?
- S
  sarah35Sep 7, 2025
  If your Samsung Microwave Oven's fan motor turns on when plugged in, it is likely due to loose wiring of the door sensing switch. Check the wire of the door sensing switch.
