30
Using "PCoIP"
2
2 Using "PCoIP"
2.2.5 Connecting to a Secondary Monitor
1 Connect [DVI OUT] on the product to [DVI IN] or [RGB IN] on another monitor using a DVI or DVI to
D-SUB cable.
The [DVI OUT] port can be used only to connect to a dual monitor.
Connect to the [DVI OUT] port to display the same picture on another monitor such as the
projector. (For presentation purposes)
The maximum resolution is 1920 x 1200 when a dual monitor is connected.
2.2.6 Connecting the Power
1 Connect the power cable to the product and the power outlet, then turn on the power switch.
(The input voltage is switched automatically).
To Next Page
