Disassembly and Assembly
32
2 Using a cross-head screwdriver, separate 3 screws on the right side of fan and a screw
on the heat-sink and then remove the right side of fan module.
Be careful not to damage the near components.
Check the number of screws that have been removed, and store them carefully
to make sure that no unassembled screws are left inside the computer during
assembly.
After you finish disassembling, refer to Fan Assembly for how to reassemble.
